Bently Nevada 3300 XL Vibration & Displacement Monitoring Module

The Bently Nevada 3300 XL Vibration & Displacement Monitoring Module is a high-reliability signal conditioning device designed to monitor shaft vibration and radial displacement in critical rotating equipment. Operating on the principle of eddy current proximity sensing, this module outputs a voltage directly proportional to the distance between the probe tip and the rotating shaft surface.

Providing a precise output signal of 7.87 V/mm (equivalent to 200 mV/mil), the unit is engineered for use with 5 mm and 8 mm 3300 XL probes, as well as compatible legacy 3300 series probes. It features high input impedance to ensure signal integrity from the sensor side, and low output impedance for accurate transmission to monitoring systems such as the Bently Nevada 3500 Series.

The module accepts a -24 VDC nominal power supply and operates in negative polarity mode. Housed in a rugged, corrosion-resistant enclosure suitable for DIN rail or panel mounting, it is specifically built for harsh, high-vibration industrial environments, including steam turbines, compressors, and other turbomachinery.

Integrated signal conditioning eliminates the need for external calibration, streamlining setup and maintenance. Standard BNC or system-specific connectors allow seamless integration into new or existing condition monitoring systems.

Specifications:

– Function: Asset Condition Monitoring
– Application: Measures vibration and shaft displacement in rotating machinery
– Output Signal: 7.87 V/mm (200 mV/mil)
– Input Voltage: -24 VDC nominal
– Output Type: Voltage proportional to shaft-probe distance
– Polarity: Negative power supply operation
– Input Impedance: High (sensor-side)
– Output Impedance: Low (system-side)
– Compatible Probes:
 – 5 mm 3300 XL
 – 8 mm 3300 XL
 – Legacy 5 mm and 8 mm 3300 series
– Connector Type: Standard BNC or system-specific
– Mounting: DIN rail or panel mountable
– Housing Material: Industrial-grade, corrosion-resistant
– Operating Temperature: -35°C to +100°C
– Humidity: Up to 95% RH non-condensing
– Shock & Vibration: Designed for high-vibration environments
– System Compatibility: Bently Nevada 3500 Series and other vibration modules
– Signal Conditioning: Integrated (no external calibration required)
– Quantity Available: Specify upon request
– Delivery: Lead time available upon inquiry

For further specifications or to inquire about this equipment and ReflowX's logistics services, Please contact ReflowX at info@reflowx.com
