Description
Description
NYY cables are low voltage power cables constructed with compact stranded copper conductors and PVC insulation. The outer sheath is manufactured from flame-retardant PVC in black, in accordance with IEC standards.
The cable is designed for indoor and outdoor installation and is manufactured to meet international and regional standards for electrical and fire performance.
Specifications
| Parameter | Details |
|---|---|
| Cable Type | NYY |
| Conductor | Compact stranded copper conductor, Class 2 |
| Conductor Standard | IEC 60228 |
| Insulation Material | PVC (Polyvinyl Chloride), 70°C |
| Sheath Material | FR-PVC (Flame Retardant PVC), Black |
| Standard (Sheath) | IEC 60502 |
| Voltage Rating | 0.6 / 1 kV |
| Maximum Conductor Temperature | 70°C (normal) / 130°C (emergency) / 250°C (short circuit ≤ 5 sec) |
| Minimum Ambient Temperature | 0°C (fixed installation) |
| Minimum Bending Radius | 12 × cable outer diameter |
Standards
| Standard Type | Details |
|---|---|
| International Standards | IEC 60502, IEC 60228, IEC 60332 |
| China Standards | GB/T 12706.1-2008 |
| Additional Standards | BS, DIN, ICEA (upon request) |
Certifications
| Certification | Details |
|---|---|
| Certifications | CE, RoHS, CCC, KEMA |
If you require any further information on this listing please contact info@reflowx.com
