- U1000 R2V 0.6/1kV EAC cetificatesed cables
Description
Description
U-1000 R2V cables are low voltage power cables manufactured with compact stranded copper conductors and XLPE insulation. The cable is protected with a flame-retardant PVC outer sheath in accordance with IEC standards.
The construction is designed for fixed installation in indoor and outdoor environments, meeting international requirements for electrical and fire performance.
Specifications
| Parameter | Details |
|---|---|
| Cable Type | U-1000 R2V |
| Conductor | Compact stranded copper conductor, Class 2 |
| Conductor Standard | IEC 60228 |
| Insulation Material | XLPE (Cross-Linked Polyethylene), 90°C |
| Sheath Material | FR-PVC (Flame Retardant PVC), Black |
| Standard (Sheath) | IEC 60502 |
| Voltage Rating | 0.6 / 1 kV |
| Maximum Conductor Temperature | 90°C (normal) / 130°C (emergency) / 250°C (short circuit ≤ 5 sec) |
| Minimum Ambient Temperature | 0°C (fixed installation) |
| Minimum Bending Radius | 8 × cable outer diameter |
Standards
| Standard Type | Details |
|---|---|
| International Standards | IEC 60502, IEC 60228, IEC/EN 60332 |
| China Standards | GB/T 12706.1-2008, GB/T19666-2019 |
| Additional Standards | BS, DIN, ICEA (upon request) |
Certifications
| Certification | Details |
|---|---|
| Certifications | CE, RoHS |
If you require any further information on this listing please contact info@reflowx.com
