- Nidec Leroy Somer Electric Motor FLSHR 160 LUR
Description
Nidec Leroy-Somer FLSHR 160 LUR Motor – Technical Specifications
General Information
- Manufacturer: Nidec Leroy-Somer
- Model: FLSHR 160 LUR
- Serial Number: 062053 A23 005
- Efficiency Class: IE3 (High Efficiency)
- Compliance: EN 12101-3 Standard for Dual-Purpose IC 411S DT
Electrical Specifications
- Power Rating: 18.5 kW
- Insulation Class: H (High thermal endurance)
- Cooling Method: IC 411 TEAO (Totally Enclosed Air Over)
- Voltage & Current Ratings:
- 380V, 50Hz: 2955 RPM, 18.5 kW, 31.1 A
- 400V, 50Hz: 2955 RPM, 18.5 kW, 32.9 A
- 690V, 50Hz: 2955 RPM, 18.5 kW, 18.0 A
- 415V, 50Hz: 2952 RPM, 18.5 kW, 31.8 A
Protection & Durability
- Protection Rating: IP55 (Dust & Water Resistant)
- Weight: 135 kg
- Construction: Rugged industrial-grade build
Environmental & Operational Conditions
- Operating Temperature: Suitable for high-temperature environments
- Mounting: Standard motor base mounting for industrial applications
For further specifications or to inquire about this equipment and ReflowX's logistics services, Please contact ReflowX at info@reflowx.com
Technical Details
| Model Number | FLSHR 160 LUR |
|---|---|
| Model Number | FLSHR 160 LUR |
| 135 kg | |
| Voltage | 380V, 50Hz |
| CFIHOS ID | CFIHOS-30000340 |
| ISO 15926 Pt 4 | 2752 |
| PCA RDS Code | RDS415124 |
| CFIHOS ID | CFIHOS-30000340 |
| Speed | 2955 RPM |
| Direction of Rotation | Clockwise |
| IFC Class | IfcElectricMotor |
| Normal Output Power | 15 kW |
| UNSPSC Code | 26101600 |
