Full Specifications

• Type: IE2 High-Efficiency Induction Motor
• Power Output:
  • 90 kW (50 Hz)
  • 100 kW (60 Hz)
• Voltage & Connection:
  • 400/690V (Star-Y Connection) - 50 Hz
  • 460V (Delta-Δ Connection) - 60 Hz
• Current Ratings:
  • 160 A / 93 A (50 Hz)
  • 139 A (60 Hz)
• Speed:
  • 1486 RPM (50 Hz)
  • 1788 RPM (60 Hz)
• Efficiency Class: IE2 (High Efficiency)
• Power Factor (Cosφ): 0.86
• Ingress Protection (IP Rating): IP55 (Dust and Water Jet Protected)
• Cooling Method: TEFC (Totally Enclosed Fan Cooled)
• Insulation Class: F (Operates within Class B temperature rise limits)
• Duty Rating: S1 (Continuous Duty)
• Mounting Type: B3 (Foot-mounted) / B5 (Flange-mounted) (Varies by Configuration)
• Frame Material: Cast Iron or Aluminum (Depending on Model)
