Description
Technical Specifications:
Manufacturer & Model
- Brand: VEM motors GmbH
- Country of Origin: Germany
- Model/Serial Number: 136109 0003 H K21R 315LX2
- Motor Type: High-Efficiency Three-Phase AC Induction Motor
Electrical & Performance Details
- Power Rating: 315 kW
- Voltage Options:
- 400V / 690V (50 Hz)
- 380V / 420V (50 Hz)
- 660V / 690V (50 Hz)
- 480V (60 Hz)
- 460V / 500V (60 Hz)
- Frequency: 50 Hz / 60 Hz
- Speed (RPM):
- 2975 RPM (50 Hz)
- 3575 RPM (60 Hz)
- Efficiency (Power Factor, Cos φ): 0.91 - 0.92
- Insulation Class: Likely Class F or H for high thermal resistance
Mechanical & Protection Features
- Ingress Protection (IP Rating): IP55 (Dust and Water Jet Protection)
- Cooling Method: Likely TEFC (Totally Enclosed Fan Cooled)
- Mounting Type: IM B3 / B5 / B35 (Based on application needs)
- Frame Size: 315L
- Weight: 1,930 kg
- Standard Compliance: DIN EN 60034-1 (International Electrical Motor Standards)
For further specifications or to inquire about this equipment and ReflowX's logistics services, Please contact ReflowX at info@reflowx.com
Technical Details
| Model Number | 136109 0003 H K21R 315LX2 |
|---|---|
| Model Number | 136109 0003 H K21R 315LX2 |
| Voltage | 400V to 690V |
| CFIHOS ID | CFIHOS-30000340 |
| Color | Blue |
| ISO 15926 Pt 4 | 2752 |
| PCA RDS Code | RDS415124 |
| CFIHOS ID | CFIHOS-30000340 |
| Direction of Rotation | Clockwise |
| IFC Class | IfcElectricMotor |
| Normal Output Power | 315 kW |
| UNSPSC Code | 26101600 |
