VTS Electric Motor: VS 132S2-4 55

ReflowX SKU: REF-7078

Product Details

Quantity

20
Availability (Lead Time)

0-2 Weeks
Product Location

United Arab Emirates
Condition

Surplus
OEM

VTS
Equipment code

CFIHOS-30000340

Get Quotation Whatsapp Chat With Seller

Short Description

Manufacturer: VTS Motor Type: VS 132S2-4 55 Serial No.: 20080030 IE Class: IE1 Certifications: CE, IEC 60034-1 Weight: 33 kg Max Frequency: 100 Hz Manufacturer: VTS Motor Type: VS 132S2-4 55 Serial No.: 20080030 IE Class: IE1 Certifications: CE, IEC 60034-1 Weight: 33 kg Max Frequency: 100 Hz Manufacturer: VTS Motor Type: VS 132S2-4 55 Serial No.: 20080030 IE Class: IE1 Certifications: CE, IEC 60034-1 Weight: 33 kg Max Frequency: 100 Hz

Description

Full Technical Specification

Motor Information

Manufacturer: VTS

Model / Type: VS 132S2-4 55

Serial No.: 20080030

Efficiency Class: IE1 (Standard Efficiency)

Certifications: CE, IEC 60034-1

Weight: 33 kg

Electrical Ratings

Max Frequency: 100 Hz (Designed for variable frequency drive applications)

Voltage & Current Ratings: (Not specified, but assumed to follow standard 132S2-4 motor configurations)

Speed: (Dependent on frequency, typically ~2800-3000 RPM @ 50 Hz)

Mechanical & Design Features

Frame Size: 132S2-4 (Indicates small to mid-size industrial motor)

Cooling Type: Likely IC 411 (Totally Enclosed Fan Cooled - TEFC)

Mounting Type: Likely IM B3 (Foot-mounted) or IM B5 (Flange-mounted) (Common for industrial motors)

Protection & Durability

Insulation Class: Likely Class F or H (For thermal protection in continuous-duty applications)

Protection Class: Likely IP55 (Dust and water jet protection for industrial environments)

Standards & Compliance

Standard Compliance: IEC 60034-1 (International motor standard)

Safety & Certification: CE Marked (Meets European safety and performance regulations)

Electrical Specifications:

Voltage (V)	Frequency (Hz)	Power (kW)	RPM	Current (A)	Power Factor (Cos φ)	Efficiency (%)
380–420V Δ	50	5.5	1435	11.3	0.84	86
660–720V Y	50	5.5	1435	6.55	0.84	86
440–480V Δ	60	6.6	1720	11.3	0.88	88
660–830V Y	60	6.6	1720	6.55	0.88	88

For further specifications or to inquire about this equipment and ReflowX's logistics services, Please contact ReflowX at info@reflowx.com

Technical Details

Model Number	VS 132S2-4 55
Model Number	VS 132S2-4 55
Weight	33 kg
Voltage	380–420V Δ
CFIHOS ID	CFIHOS-30000340
ISO 15926 Pt 4	2752
PCA RDS Code	2752
CFIHOS ID	CFIHOS-30000340
Speed	~2800-3000 RPM
Direction of Rotation	Clockwise
IFC Class	IfcElectricMotor
Explosion Protection Gas Group	IIC
Explosion Protection Temperature Class	T3 or T4
Explosion Protection Zone	Zone 1 or Zone 2
UNSPSC Code	26101600
