WEG 340 kW Explosion-Proof Three-Phase Induction Motor (Spare Part) – Squirrel Cage

ReflowX SKU: REF-6677

Product Details

Quantity

1
Availability (Lead Time)

0-2 Weeks
Product Location

Brazil
Condition

New
OEM

Weg
Equipment code

CFIHOS-30000340
Total Price
Per Unit Price

$ 21,000.00

Short Description

A 340 kW WEG explosion-proof three-phase induction motor built for reliable performance in hazardous environments. Designed for heavy-duty industrial use, this spare part ensures safety, durability, and compliance with ATEX and IEC standards.

Description

The WEG 340 kW explosion-proof three-phase induction motor is a heavy-duty unit designed for continuous operation in hazardous and high-demand industrial applications. Built with precision engineering and superior insulation, it provides dependable performance and meets ATEX, IEC, and ISO standards for explosion protection.

Specifications:
– Brand / Model: WEG 355 M / L 04
– Manufacturer: WEG Group Africa (Pty) Ltd
– Manufacturing Location: Portugal
– Motor Type: Explosion-Proof Three-Phase Induction Motor – Squirrel Cage
– Standard Compliance: CE1180 EX II 2G EEx d IIB T4, EN 50014:1997 + A1:1999 + A2:1995, ISSeP 06 ATEX 026
– Rated Voltage: 380 V
– Frequency: 50 Hz
– Rated Power Output: 340 kW
– Power Factor (Cos φ): 0.87
– Rated Current: 616 A
– Full Load Speed: 1488 rpm
– Insulation Class: F / Δ 75K
– Degree of Protection: IP55
– Duty Cycle: S1 (Continuous)
– Ambient Temperature Limit: 45°C
– Altitude Rating: Up to 1000 m above sea level
– Service Factor: 1.15
– Bearing Type (Drive End): 6322-C3
– Bearing Type (Non-Drive End): 6319-C3 INS
– Grease Type: POLYREX EM Esso
– Approx. Weight: 2100 kg
– Dimensions (L × W × H): 180 × 115 × 90 cm
– Color: Industrial Green
– Condition: Spare part (used, in working condition)
– Country of Origin: Portugal

For further specifications or to inquire about this equipment and ReflowX’s logistics services, please contact ReflowX at info@reflowx.com.

Technical Details

Model Number	355 M / L 04
Model Number	355 M / L 04
Weight	2100 Kg
Voltage	380V
