Description

CU/XLPE/CWS/PVC cables are manufactured with compact stranded copper conductors and XLPE insulation, incorporating semi-conductive conductor and insulation screens. The design includes a copper wire screen with helical copper tape and a PVC or FR-PVC outer sheath.

The cable is produced in accordance with IEC standards for high voltage power distribution applications.

Specifications

– Cable Type: CU/XLPE/CWS/PVC High Voltage Cable
– Conductor: Compact stranded copper, Class 2 (IEC 60228)
– Conductor Screen: Semi-conductive
– Insulation Material: XLPE (Cross-Linked Polyethylene), 90°C
– Insulation Screen: Semi-conductive
– Screening: Copper wire screen with helical copper tape (CWS)
– Sheath Material: PVC or FR-PVC Type ST2, Black
– Sheath Standard: IEC 60502
– Voltage Rating: 18 / 30 kV
– Maximum Conductor Temperature: 90°C (normal) / 130°C (emergency) / 250°C (short circuit ≤ 5 sec)
– Minimum Ambient Temperature: 0°C (fixed installation)
– Minimum Bending Radius: 20 × cable O.D (single core) / 15 × cable O.D (multi core)

Standards

– IEC 60502
– IEC 60228
– IEC 60332-3 (ZR-YJV only)
– GB/T 12706
– GB/T 18380-3 (ZR-YJV only)
– BS, DIN, ICEA (upon request)
