Claudius Peters GM 25 S High-Pressure Air Handling Unit – 2011

Manufactured by Claudius Peters Technologies GmbH in Germany, the GM 25 S is a high-speed, high-pressure air handling machine tailored for demanding industrial pneumatic conveying systems. With a robust build and a speed of 3480 RPM, this unit is capable of generating an overpressure of 0.800 bar while operating under a suction pressure of 1.000 bar (atmospheric). It consumes 36.75 kW of power and supports maximum operating temperatures up to 135°C. The GM 25 S is constructed from heavy-duty industrial-grade steel and includes an air-cooled system, automatic lubrication, and high-performance bearings for continuous, maintenance-minimized operation. Ideal for use in cement, gypsum, and bulk handling plants, this unit ensures reliable performance under rigorous environmental conditions.

Specifications:

– Model: GM 25 S
– Manufacturer: Claudius Peters Technologies GmbH
– Year of Manufacture: 2011
– Order Number: 213783
– Machine Number: 16401
– Medium: Air (pneumatic conveying)
– Speed: 3480 RPM
– Power Consumption: 36.75 kW
– Suction Pressure: 1.000 bar (Atmospheric)
– Overpressure (Pe): 0.800 bar
– Max Operating Temperature: 135°C
– Cooling System: Air-cooled
– Lubrication: Automatic lubrication system
– Bearings: High-performance bearings for high-speed operation
– Drive System: Electric motor-driven
– Construction: Industrial-grade steel body
– Country of Origin: Germany

For further specifications or to inquire about this equipment and ReflowX's logistics services, Please contact ReflowX at info@reflowx.com
