90° Elbows – Carbon Steel & Stainless Steel, SCH10 to SCH160, ½” to 36”
Description:

These 90° Elbows are engineered pipe fittings designed to enable smooth directional changes in piping systems. Manufactured from premium carbon steel (SA234 WPB) and stainless steel (SA403 WP304/316), these elbows are available in a wide size range from ½ inch to 36 inches with wall thickness options of SCH10, SCH40, SCH80, and SCH160. The elbows comply with ASME B16.9 and ASTM specifications to ensure high quality and reliable performance in various industrial applications including oil & gas, petrochemical, power generation, and water treatment plants. Sourced from Hebei China, Taiwan, and Korea, these fittings provide excellent corrosion resistance and strength, suitable for high-pressure and temperature environments.

Specification:

– Product Type: 90 Degree Elbow
– Materials:
 • Carbon Steel – SA234 WPB
 • Stainless Steel – SA403 WP304, SA403 WP316
– Size Range: ½” to 36” (DN15 to DN900)
– Wall Thickness: SCH10, SCH40, SCH80, SCH160
– Bend Angle: 90 degrees
– End Preparation: Beveled ends for butt welding (ASME B16.9 compliant)
– Manufacturing Standards: ANSI/ASME B16.9, MSS-SP-75
– Surface Finish:
 • Carbon Steel – Black coated or bare
 • Stainless Steel – Pickled or polished finish
– Origin: Hebei (China), Taiwan, Korea
– Typical Applications: Oil & gas pipelines, chemical process lines, power plants, industrial fluids
– Markings: Size, schedule, heat number, manufacturer stamp
– Quality Assurance: Dimensional checks, hydrostatic testing (if applicable), PMI

For further specifications or to inquire about this equipment and ReflowX's logistics services, Please contact ReflowX at info@reflowx.com
