Steel Pipe Elbows – 45°, 90°, 180° | ANSI B16.9 / MSS-SP75 / DIN2605 | WPB / WPL6 | SR & LR

These high-quality steel pipe elbows are designed for industrial piping systems requiring reliable directional flow changes. Available in 45°, 90°, and 180° bend types, the elbows are fabricated to international standards such as ANSI B16.9, MSS-SP75, and DIN2605 (Teil 1 / Teil 2), ensuring precision and durability. Elbows are offered in both short radius (SR) and long radius (LR) designs for optimal fit based on space constraints and flow dynamics. Constructed from robust carbon steel grades including ASTM A234 WPB and WPL6, these elbows are suitable for use in oil & gas, petrochemical, power generation, and other demanding applications. The elbows meet dimensional and material criteria set by ANSI B16.28 for consistent quality across critical piping installations.

Specifications:

– Product Type: Steel Pipe Elbows
– Bend Angles: 45°, 90°, 180°
– Radius Options:
 • Short Radius (SR)
 • Long Radius (LR)
– Standards:
 • ANSI B16.9
 • MSS-SP75
 • ANSI B16.28
 • DIN 2605 Teil 1 / Teil 2
– Material Grades:
 • ASTM A234 WPB
 • ASTM A234 WPL6
– Connection Type: Butt-Weld
– Form: Seamless or Welded (based on availability and size)
– Pressure Rating: As per ASME B31.3 (depends on wall thickness and grade)
– Finish: Black Painted / Bare / Galvanized (optional)
– Applications: Oil & Gas, Refining, Chemical Processing, Power Plants, Water Pipelines
– Certification: Supplied with mill test certificates and traceability to heat number
For further specifications or to inquire about this equipment and ReflowX's logistics services, Please contact ReflowX at info@reflowx.com
