PROSONIC M Ultrasonic Flowmeter Endress+Hauser – FMU41-ANE2C4

The Endress+Hauser PROSONIC M FMU41 Ultrasonic Flowmeter is a versatile, non-contact level and flow measurement instrument designed for continuous measurement of liquids in open channels and tanks. Built for harsh industrial environments, this unit offers flexible wiring options with either two-wire or four-wire configurations and supports industry-standard communication protocols including 4–20 mA with HART, PROFIBUS PA, and FOUNDATION Fieldbus. With a power-efficient design (0.8 W typical), integrated temperature compensation, and high accuracy of ±3 mm or ±0.2% of span, the PROSONIC M ensures consistent performance even in extreme temperatures down to -60°C. Certified for IP68/NEMA 6P protection and Ex d [ia Ga] IIC T6 Ga/Gb hazardous zones, it is ideal for applications in the chemical, water treatment, and oil & gas sectors.

Specifications:

– Device Name: Ultrasonic Flowmeter
– Manufacturer: Endress+Hauser
– Model: PROSONIC M
– Order Code: FMU41-ANE2C4
– Serial Number: J600042500A
– Manufacturing Location: Endress+Hauser, Suzhou – China
– Standard: 14–30 V DC, 0.8 W
– Two-wire version: 16–30 V DC
– Four-wire version: 85–265 V AC or 16–30 V DC
– Wiring: 2-wire system
– Output: 4–20 mA with HART (standard)
– Optional: PROFIBUS PA / FOUNDATION Fieldbus
– Display: Optional integrated 4-line plain text
– Accuracy: ±3 mm or ±0.2% of span (whichever is greater)
– Resolution: 1 mm
– Response Time: Adjustable; ~1 second typical
– Temperature Compensation: Integrated sensor
– Temperature Range: Down to −60°C
– Enclosure Protection: IP68, NEMA 6P
– Explosion Protection: Ex d [ia Ga] IIC T6 Ga/Gb (Flameproof & Intrinsically Safe)

For further specifications or to inquire about this equipment and ReflowX’s logistics services, please contact info@reflowx.com
