Caterpillar 966H Wheel Loader - 2010

ReflowX SKU: REF-8706

Product Details

Quantity

1
Availability (Lead Time)

0-2 Weeks
Product Location

United Arab Emirates
Condition

Surplus
OEM

Caterpillar
Equipment code

Get Quotation Whatsapp

Short Description

Heavy-duty wheel loader powered by the Caterpillar C11 ACERT™ engine delivering 195 kW net power, featuring a 3.2–4.2 m³ bucket, planetary power shift transmission, and load-sensing hydraulics. Built for demanding material handling in quarry, mining, and construction operations.

Description

Caterpillar 966H Wheel Loader - 2010

The Caterpillar 966H Wheel Loader (2010) is an industry-standard machine renowned for its strength, durability, and efficiency in heavy-duty loading applications. Powered by the fuel-efficient C11 ACERT™ diesel engine, it meets EPA Tier 3 and EU Stage IIIA emissions standards. With a robust operating weight of 23 tonnes, and high breakout and lifting forces, the 966H ensures excellent performance for high-volume material handling. Its advanced power shift transmission, load-sensing hydraulics, and ergonomic cabin provide unmatched productivity, operator comfort, and control in the harshest environments.

Specifications:

– Make & Model: Caterpillar 966H
– Year of Manufacture: 2010
– Asset Code: FM-187
– Reference / PO: PO-303
– Type: Wheel Loader
– Engine Model: Caterpillar C11 ACERT™
– Gross Power: 221 kW (296 HP)
– Net Power: 195 kW (262 HP) @ 1,800 RPM
– Displacement: 11.1 L (678 in³)
– Torque: 1,608 Nm @ 1,200 RPM
– Aspiration: Turbocharged & Aftercooled
– Fuel Type: Diesel
– Emission Compliance: EPA Tier 3 / EU Stage IIIA
– Operating Weight: Approx. 23,000 kg (50,706 lbs)
– Breakout Force: ~183 kN
– Bucket Capacity: 3.2 to 4.2 m³ (4.2 to 5.5 yd³)
– Dump Clearance @ Max Lift: 3,190 mm (10.5 ft)
– Static Tipping Load (Full Turn): ~15,400 kg
– Type: Caterpillar Planetary Power Shift
– Speeds: 4 Forward / 4 Reverse
– Max Forward Speed: ~38 km/h (23.6 mph)
– Max Reverse Speed: ~27 km/h (16.8 mph)
– Torque Converter: Single-stage, 3-element
– Hydraulic System Type: Load-Sensing, Variable Displacement
– Main Pump Flow Rate: ~385 L/min
– Relief Valve Pressure: ~31,000 kPa (4,496 psi)
– Cycle Time (Raise): ~5.4 seconds
For further specifications or to inquire about this equipment and ReflowX's logistics services, Please contact ReflowX at info@reflowx.com

Technical Details

Model Number	966H
Year of Manufacturing	2010
Height	11.74 ft
Width	10.56 ft with bucket
Length	29.01 ft with bucket on ground
Weight	23,000 kg
ISO 15926 Pt 4	8929
PCA RDS Code	RDS5800251
CFIHOS ID	CFIHOS-30000597
Fuel type	Diesel
