Caterpillar 950G Wheel Loader – 145 kW, 2.7 m³ Bucket, 4WD

The Caterpillar 950G is a powerful and versatile wheel loader designed to meet the demanding needs of construction, quarrying, and industrial operations. Equipped with the robust Caterpillar 3116 6-cylinder turbocharged diesel engine, the machine delivers a rated output of 145 kW (194 HP) at 2,200 rpm and meets Tier 2 emission standards.

Built to handle tough loads, the 950G boasts a 2.7 m³ (3.5 yd³) bucket capacity and a maximum breakout force of 11,800 kg (25,982 lbs), ensuring efficient digging and loading operations. The loader’s rated operating capacity is 4,150 kg, with a tipping load of 9,300 kg. Its high lift height of 3,500 mm and a maximum dump clearance of 2,420 mm make it well-suited for truck loading and material stacking.

The machine features a 4WD drivetrain for traction and stability across varied terrains. Heavy-duty 20.5-25 radial tires, a top travel speed of 38 km/h, and a tight turning radius of 5.7 m enhance maneuverability and site productivity. With a fuel tank capacity of 310 liters, the 950G supports extended work cycles with reduced refueling intervals.

Specifications:

– Model: Caterpillar 950G
– Manufacturer: Caterpillar Inc.
– Engine Model: Caterpillar 3116
– Engine Type: 6-cylinder, turbocharged diesel
– Rated Power Output: 145 kW (194 HP) @ 2,200 rpm
– Displacement: 7.0 L
– Emission Standard: Tier 2
– Maximum Operating Weight: 16,500 kg (36,376 lbs)
– Bucket Capacity: 2.7 m³ (3.5 yd³)
– Max Lift Height: 3,500 mm (11.5 ft)
– Max Dump Clearance: 2,420 mm (7.9 ft)
– Max Reach at Full Lift: 1,060 mm (3.5 ft)
– Breakout Force: 11,800 kg (25,982 lbs)
– Tipping Load: 9,300 kg (20,500 lbs)
– Rated Operating Capacity: 4,150 kg (9,150 lbs)
– Drive Type: 4WD
– Tires: 20.5-25 (radial)
– Maximum Speed: 38 km/h (24 mph)
– Turning Radius: 5.7 m (18.7 ft)
– Gradeability: 35%
– Fuel Tank Capacity: 310 L

For further specifications or to inquire about this equipment and ReflowX's logistics services, Please contact ReflowX at info@reflowx.com
