SANY STC1300T 130-Ton Truck Crane

ReflowX SKU: REF-6319

Product Details

Quantity

1
Availability (Lead Time)

0-2 Weeks
Product Location

China
Condition

Surplus
OEM

FC Machinery Equipment Co. Limited
Equipment code
Shipping Rate

Get Quotation Whatsapp

Short Description

The SANY STC1300T is a 130-ton truck crane featuring a 75.5-meter 7-section boom and a 17.5-meter jib, delivering a maximum lifting moment of 4390 kN·m. With a counterweight up to 46 tons and 8.1-meter outrigger span, its estimated operating weight is ~54,000 kg.

Description

SANY STC1300T 130-Ton Truck Crane
Description:

The SANY STC1300T is a high-performance 130-ton truck-mounted crane engineered for major lifting operations across industrial, energy, and infrastructure projects. It features a 7-section, 75.5-meter main boom and an optional 17.5-meter jib, enabling a maximum lifting height of 102.5 meters.

Powered by a Weichai WP10.5H430E62 engine, the crane ensures robust and efficient performance under load. The maximum lifting moment of 4390 kN·m at the basic boom section highlights its power and versatility for heavy-duty jobs.

The counterweight system, rated at 41 tons and expandable to 46 tons, paired with an 8.1-meter outrigger span, ensures maximum stability and safety during operation. The overall transport dimensions are 16000 × 3000 × 4000 mm, and the estimated total machine weight is approximately 54,000 kg, offering a balance of transportability and lifting strength.

Specifications:

– Product Type: Truck Crane
– Brand: SANY
– Model: STC1300T
– Max. Lifting Capacity: 130 tons
– Max. Boom Length: 75.5 meters
– Max. Jib Length: 17.5 meters
– Max. Lifting Height: Up to 102.5 meters
– Max. Lifting Moment: 4390 kN·m
– Boom Type: 7-section telescopic boom
– Engine Model: Weichai WP10.5H430E62
– Engine Power: Approx. 316 kW (430 HP)
– Counterweight: 41 tons (expandable to 46 tons)
– Outrigger Span: 8.1 meters
– Overall Dimensions (L × W × H): 16000 × 3000 × 4000 mm
– Estimated Operating Weight: **~54,000 kg**
– Applications: Heavy infrastructure, high-rise, energy, and industrial lifting
For further specifications or to inquire about this equipment and ReflowX's logistics services, Please contact ReflowX at info@reflowx.com

Technical Details

Model Number	STC1300T
Manufacturer Name	SANY
Counterweight	41 tons
Max. Lifting Capacity	130 tons
Max. Boom Length	75.5 meters
Max. Jib Length	17.5 meters
Max. Lifting Moment(KN.m)	4390 kN·m
Engine Model	Weichai WP10.5H430E62
Overall dimensions (length x width x height) (mm)	16000 × 3000 × 4000 mm
