SANY STC700T5 70-Ton Hydraulic Truck Crane
Description:

The SANY STC700T5 is a powerful and versatile 70-ton truck-mounted crane designed for high-demand lifting operations such as bridge construction, industrial installations, and high-rise infrastructure development. Equipped with a high-performance Weichai WP10H375E62 engine generating 298 kW, it ensures strong torque delivery and complies with strict emission regulations.

This model features a 55-meter telescopic main boom and a 20-meter jib, providing a maximum lifting height of up to 75 meters. With a maximum lifting moment of 3146 kN·m and a robust 24.8-ton counterweight, the STC700T5 ensures outstanding load stability and reach over wide working radii.

Mounted on a durable 4-axle chassis, this crane is both highway-legal and site-capable, allowing fast deployment between job sites. Its advanced hydraulic system ensures precise boom control and efficient lifting operations. The compact size—14970 × 2800 × 3880 mm—enhances maneuverability while retaining powerful lifting capacity, making it a practical solution for modern lifting demands.

Specifications:

– Product Type: Hydraulic Truck Crane
– Brand: SANY
– Model: STC700T5
– Rated Lifting Capacity: 70 tons
– Max. Boom Length: 55 meters
– Max. Jib Length: 20 meters
– Max. Lifting Height (with jib): 75 meters
– Max. Lifting Moment: 3146 kN·m
– Counterweight: 24.8 tons
– Engine Model: Weichai WP10H375E62
– Engine Power: 298 kW
– Chassis: 4-axle heavy-duty
– Overall Dimensions (L × W × H): 14,970 × 2800 × 3880 mm
– Applications: High-rise construction, bridge lifting, precast segments, heavy industrial installations
– Special Features: Advanced hydraulics, emission-compliant engine, fast boom deployment
