XCMG 25K5-1 25-Ton Hydraulic Truck Crane
Description:

The XCMG 25K5-1 is a high-performance 25-ton truck crane built for demanding construction, transport, and installation tasks. It boasts a maximum lifting capacity of 25 tons and a powerful lifting moment of 961 kN·m. Its robust octagonal main boom extends up to 39.5 meters, and with the 8.3-meter jib, the maximum lifting height reaches 47.8 meters. Powered by a SC8DK280Q3 or SC9DF300.1Q5 engine delivering up to 221 kW, the crane achieves a top speed of 80 km/h and a climbing gradeability of 40%. The advanced hydraulic system and durable chassis structure ensure stable, precise, and energy-efficient lifting operations. With a 6-ton counterweight and optimized design, the XCMG 25K5-1 offers excellent maneuverability, reliability, and ease of maintenance for on-site efficiency.

Specification:

– Product Type: Hydraulic Truck Crane
– Brand: XCMG
– Model: 25K5-1
– Rated Lifting Capacity: 25 tons
– Max. Boom Length: 39.5 meters
– Max. Jib Length: 8.3 meters
– Max. Lifting Height (With Jib): 47.8 meters
– Max. Lifting Moment: 961 kN·m
– Counterweight: 6 tons
– Engine Model: SC8DK280Q3 or SC9DF300.1Q5
– Rated Engine Power: Up to 221 kW
– Max. Travel Speed: 80 km/h
– Gradeability: 40%
– Boom Type: 5-section Octagonal Boom
– Hydraulic System: Advanced energy-efficient hydraulic system
– Chassis Type: Heavy-duty truck chassis
– Suspension: Reinforced leaf spring system
– Cabin: Ergonomic operator cabin with advanced controls
– Safety Systems: Overload protection, emergency stop, anti-slewing brake
– Applications: Construction, transportation, installation
– Overall Dimensions (L × W × H): 12300 × 2500 × 3350 mm
For further specifications or to inquire about this equipment and ReflowX's logistics services, Please contact ReflowX at info@reflowx.com
