XCMG QY25K5-2 - 25-Ton Hydraulic Truck Crane
Long Description:

The XCMG QY25K5-2 truck crane is a robust and high-performance lifting machine designed for demanding job site environments. It boasts a rated lifting capacity of 25 tons, with a 40.7-meter maximum boom length and a 9-meter jib, providing a broad and flexible working range. The SC9DF290Q6 high-power engine delivers excellent torque and responsiveness, ensuring strong and efficient operation. Its large 6-ton counterweight, combined with an optimized structural design and wide outrigger span, guarantees outstanding stability and lifting safety. The crane is also equipped with intelligent control and safety systems, including overload protection, boom angle indicators, and emergency shut-offs, making it highly reliable and easy to operate. This model is ideal for construction, logistics, infrastructure, and industrial installation projects.

Specification:

– Product Type: Hydraulic Truck Crane
– Brand: XCMG
– Model: QY25K5-2
– Rated Lifting Capacity: 25 tons
– Max. Boom Length: 40.7 meters
– Max. Jib Length: 9 meters
– Max. Lifting Moment: 961 kN·m
– Counterweight: 6 tons
– Engine Model: SC9DF290Q6 (High-power diesel engine)
– Drive Type: 6×4
– Transmission: Manual (9-speed or similar)
– Max. Travel Speed: Approx. 80 km/h
– Gradeability: Approx. 30%
– Steering System: Hydraulic power-assisted
– Brake System: Dual-circuit air brake with auxiliary retarder
– Suspension: Leaf spring suspension system
– Tires: 11.00R20 or equivalent
– Outrigger Span (L × W): Approx. 5.3 m × 6.2 m
– Operator Cabin: Ergonomic cab with integrated safety controls and display systems
– Safety Features: Load moment indicator, anti-overturn system, boom angle limiter, emergency shutdown
– Fuel Efficiency: Optimized engine and hydraulic system for reduced fuel consumption
– Applications: Building construction, lifting operations, infrastructure, industrial maintenance
– Overall Dimensions (L × W × H): 12850 mm × 2550 mm × 3480 mm
– Operating Weight: Approx. 31,500–32,000 kg
For further specifications or to inquire about this equipment and ReflowX's logistics services, Please contact ReflowX at info@reflowx.com
