XCMG QY40KC 40-Ton Hydraulic Truck Crane
Description:

The XCMG QY40KC is a high-performance 40-ton hydraulic truck crane designed to deliver powerful lifting capabilities and reliable on-site operation. Equipped with a 5-section, 44-meter main boom and optional 9.5-meter or 16-meter jibs, the crane achieves a maximum lifting height of up to 60.3 meters. With a rated lifting moment of 1574 kN·m and a 9.5-ton counterweight, the QY40KC handles demanding loads with precision and stability. It is powered by the SC9DF340Q5 engine, delivering 251 kW of rated power, a maximum travel speed of 90 km/h, and 45% gradeability for strong mobility on various terrains. The crane features a luxury operator cabin, advanced hydraulic system, and a robust chassis, making it ideal for construction, infrastructure development, and industrial lifting tasks. Its intelligent control systems and comfortable operation environment further enhance safety and productivity on the job.

Specification:

– Product Type: Hydraulic Truck Crane
– Brand: XCMG
– Model: QY40KC
– Rated Lifting Capacity: 40 tons
– Max. Boom Length: 44 meters
– Max. Jib Length: 16 meters
– Max. Lifting Height (With Jib): Approx. 60.3 meters
– Max. Lifting Moment: 1574 kN·m
– Counterweight: 9.5 tons
– Engine Model: SC9DF340Q5 (Rated Power: 251 kW)
– Max. Travel Speed: 90 km/h
– Gradeability: 45%
– Boom Type: 5-section U-type high-strength steel boom
– Hydraulic System: Energy-saving and precision hydraulic control system
– Operator Cabin: Luxury cab with ergonomic layout and advanced monitoring
– Applications: Construction, infrastructure, industrial lifting
– Overall Dimensions (L × W × H): 13745 × 2800 × 3560 mm
