XCMG XCT20L5 20-Ton Hydraulic Truck Crane

ReflowX SKU: REF-6516

Product Details

Quantity

1
Availability (Lead Time)

0-2 Weeks
Product Location

China
Condition

Surplus
OEM

FC Machinery Equipment Co. Limited
Equipment code
Shipping Rate

Get Quotation Whatsapp

Short Description

The XCMG XCT20L5 is a 20-ton capacity truck crane with a 40-meter U-type boom, high-performance engine, and energy-saving hydraulic system, delivering efficient and stable lifting operations.

Description

XCMG XCT20L5 20-Ton Hydraulic Truck Crane
Description:

The XCMG XCT20L5 is a versatile 20-ton truck-mounted crane engineered for high efficiency, precision, and operational flexibility. It features a 5-section 40-meter U-type main boom and an 8.3-meter jib, offering a maximum lifting height of 47.6 meters and a working radius of up to 38.4 meters. Powered by the SC7H260Q5 engine rated at 192 kW, the XCT20L5 delivers robust performance across various terrains and lifting scenarios. The crane incorporates an advanced energy-saving hydraulic system with a hoisting speed of 2.5 m/min and slewing speed of 0.1°/s, ensuring smooth, safe, and cost-effective operation. A counterweight of 6.5 tons enhances stability, making the XCT20L5 ideal for construction, transportation, infrastructure, and general lifting operations.

Specification:

– Product Type: Hydraulic Truck Crane
– Brand: XCMG
– Model: XCT20L5
– Rated Lifting Capacity: 20 tons
– Max. Boom Length: 40 meters
– Max. Jib Length: 8.3 meters
– Max. Lifting Height: 47.6 meters
– Max. Working Radius: 38.4 meters
– Max. Lifting Moment: 900 kN·m
– Counterweight: 6.5 tons
– Engine Model: SC7H260Q5
– Rated Engine Power: 192 kW
– Hydraulic System: Energy-saving design with 2.5 m/min lifting speed and 0.1°/s slewing speed
– Drive Type: Likely 4x2 or 6x4 (model-dependent)
– Transmission: Manual/Automatic (depending on configuration)
– Suspension System: Heavy-duty leaf spring suspension
– Braking System: Dual-circuit air brake with auxiliary braking system
– Outrigger Span: Wide span for enhanced operational stability
– Operator Cabin: Ergonomic with safety glazing and climate control options
– Safety Features: Overload protection, emergency stop, anti-tipping system
– Applications: Construction, transport, infrastructure, industrial lifting
– Maintenance: Easy access for low-maintenance service routines
– Overall Dimensions (L × W × H): 12262 mm × 2500 mm × 3410 mm
For further specifications or to inquire about this equipment and ReflowX's logistics services, Please contact ReflowX at info@reflowx.com

Technical Details

Model Number	XCT20L5
Manufacturer Name	XCMG
Counterweight	6.5
Max. Lifting Capacity	20
Max. Boom Length	40
Max. Jib Length	8.3
Max. Lifting Moment(KN.m)	900
Engine Model	SC7H260Q5
Overall dimensions (length x width x height) (mm)	12262×2500×3410
