XCMG XCT25L5 25-Ton Hydraulic Truck Crane
Description:

The XCMG XCT25L5 is a high-performance 25-ton hydraulic truck crane designed for demanding construction and infrastructure applications. It features a robust 5-section, 42-meter U-type main boom, providing a maximum lifting height of 50.2 meters and a working radius of 38.5 meters. The crane is powered by an SC9DF290.1Q4 or SC9DF290.2Q4 engine delivering 213 kW, ensuring powerful and reliable operation. It boasts a maximum travel speed of 90 km/h and 45% gradeability for excellent mobility. The advanced energy-saving hydraulic system enhances precision and efficiency, with a lifting speed of 2.5 m/min and slewing speed of 0.1°/s. With a 5.5-ton counterweight and optimized design, the XCT25L5 provides outstanding stability and safety, making it ideal for a wide range of lifting projects.

Specification:

– Product Type: Hydraulic Truck Crane
– Brand: XCMG
– Model: XCT25L5
– Rated Lifting Capacity: 25 tons
– Max. Boom Length: 42 meters
– Max. Jib Length: 9 meters
– Max. Lifting Height: 50.2 meters
– Max. Working Radius: 38.5 meters
– Max. Lifting Moment: 1132 kN·m
– Counterweight: 5.5 tons
– Engine Model: SC9DF290.1Q4 or SC9DF290.2Q4
– Rated Engine Power: 213 kW
– Max. Travel Speed: 90 km/h
– Gradeability: 45%
– Hydraulic System: Energy-saving system (lifting speed: 2.5 m/min, slewing speed: 0.1°/s)
– Boom Type: 5-section U-type main boom
– Outrigger Span: Wide for high stability
– Drive System: Heavy-duty truck chassis
– Suspension System: Reinforced leaf spring suspension
– Operator Cabin: Ergonomic design with panoramic visibility and controls
– Safety Features: Overload limiter, anti-slewing brake, emergency stop
– Applications: Construction, transport, industrial lifting, infrastructure
– Overall Dimensions (L × W × H): 12870 × 2500 × 3470 mm
For further specifications or to inquire about this equipment and ReflowX's logistics services, Please contact ReflowX at info@reflowx.com
