ZOOMLION 50H 50-Ton Hydraulic Truck Crane
Description:

The ZOOMLION 50H is a high-capacity 50-ton truck crane, designed to meet the demanding needs of lifting operations in construction, infrastructure, and industrial projects. With a main boom length of 42 meters and optional 9.5-meter or 16-meter jibs, this crane is capable of reaching elevated positions for a wide range of applications.

It delivers a maximum lifting moment of 1764 kN·m at the basic arm, demonstrating excellent load-handling strength. The unit is powered by the robust and fuel-efficient Weichai WP10.336 engine, offering smooth and dependable performance across varied terrains. It achieves a top travel speed of 76 km/h, enabling fast jobsite transfers to keep up with dynamic project demands.

Stability is key in lifting operations, and the 50H achieves this with a 10-ton counterweight system and 6.9-meter wide fully extended outriggers, providing enhanced anti-tilt capability. Its ergonomic cab, advanced hydraulic system, and structural steel boom contribute to high operational efficiency and long-term durability.

Specifications:

– Product Type: Hydraulic Truck Crane
– Brand: ZOOMLION
– Model: 50H
– Rated Lifting Capacity: 50 tons
– Max. Boom Length: 42 meters
– Max. Jib Length: 9.5 or 16 meters
– Max. Lifting Moment (Base Boom): 1764 kN·m
– Counterweight: 10 tons
– Engine Model: Weichai WP10.336
– Engine Power: Approx. 247 kW (336 HP)
– Transmission: Manual, multi-speed
– Max. Travel Speed: 76 km/h
– Gradeability: ~40%
– Outrigger Span (L × W): 6.9 meters (fully extended)
– Boom Type: 5-section, U-shaped telescopic boom
– Crane Weight (Driving Mode): **Approx. 39,000–41,000 kg** (subject to jib and counterweight config)
– Operator Cabin: Ergonomic design, HVAC, panoramic view
– Hydraulic System: Load-sensing for precision control
– Overall Dimensions (L × W × H): 13300 × 2750 × 3550 mm
– Applications: Heavy lifting, structural installation, bridgeworks, plant erection
For further specifications or to inquire about this equipment and ReflowX's logistics services, Please contact ReflowX at info@reflowx.com
