DYNAPAC - Graders CC1200 Road Roller – 2016

The Dynapac CC1200 Road Roller (2016) is a high-performance double drum vibratory compactor designed for efficient asphalt and sub-base compaction in medium- to large-scale projects. Powered by a Deutz TCD 3.6 L4 turbocharged diesel engine, the roller delivers 74.9 kW (100 HP), providing high torque and low fuel consumption.

Weighing 12,000 kg, this roller features a dual-frequency vibration system with selectable high and low amplitude settings for versatile applications. It achieves 54 kN centrifugal force at 28 Hz for heavy compaction and 33 kN at 18 Hz for lighter surface finishes. The smooth drum (with optional padfoot) has a drum width of 2,000 mm and a diameter of 1,400 mm, delivering uniform compaction across the work area.

With a max speed of 10 km/h and a hydraulic system pressure of 320 bar, the CC1200 ensures rapid job completion with precise control. The roller also features an 800-liter water tank and drum scrapers to maintain optimal surface wetting and reduce material buildup.

Specifications:

– Model: Dynapac CC1200
– Year: 2016
– Type: Vibratory Road Roller / Compactor
– Operating Weight: 12,000 kg

– Engine Model: Deutz TCD 3.6 L4
– Engine Power: 74.9 kW (100 HP)
– Engine Type: 4-cylinder, Turbocharged Diesel
– Fuel Tank Capacity: 170 liters

– Overall Length: 3,550 mm
– Overall Width: 2,300 mm
– Overall Height: 2,890 mm
– Wheelbase: 2,560 mm
– Ground Clearance: 345 mm
– Track Width: 1,200 mm

– Drum Type: Smooth drum (padfoot optional)
– Drum Width: 2,000 mm
– Drum Diameter: 1,400 mm
– Scraper: Equipped with drum scraper
– Vibration Type: Dual-frequency vibration

– Centrifugal Force:
 – 54 kN (High amplitude)
 – 33 kN (Low amplitude)
– Vibration Frequency:
 – 28 Hz (High)
 – 18 Hz (Low)
– Amplitude:
 – 1.8 mm (High)
 – 0.9 mm (Low)

– Max Working Pressure: 320 bar
– Water Tank Capacity: 800 liters

– Max Travel Speed: 10 km/h

For further specifications or to inquire about this equipment and ReflowX's logistics services, Please contact ReflowX at info@reflowx.com
