- HT 10C Mini Excavator – Koop Engine, 1000kg, 7kW Power
Description
Product Description
Overview
The HT-10C Mini Excavator is a compact and efficient solution for a variety of digging and earth-moving tasks. Powered by a KOOP 192F engine, this mini excavator provides reliable performance in challenging conditions, ensuring reduced downtime and prolonged service life. It is equipped with advanced safety features, including a waterproof key, seat belt, and high-strength hydraulic components.
Key Features
| Feature | Specification |
|---|---|
| Engine | KOOP 192F (Single Cylinder, Fan Cool) |
| Optional Engines | Briggs & Stratton, Yanmar |
| Rated Power | 7kW at 3000 RPM |
| Main Pump | G5-6 with 6.8ml/r displacement |
| Traveling Motor | SANYANG BMT-245 |
| Swing Motor | SANYANG BMRS-250 |
| Travel Speed | 1.5 km/h |
| Overall Dimensions (L x W x H) | 2775 x 930 x 2219 mm |
| Track Width | 180 mm |
| Chassis Ground Clearance | 132 mm |
| Platform Ground Clearance | 380 mm |
| Max Digging Depth | 1650 mm |
| Max Dumping Height | 1850 mm |
| Max Digging Radius on Ground | 2850 mm |
| Max Upgrade Height of Blade | 345 mm |
| Max Digging Depth with Blade | 255 mm |
Oil Supply System
Lubricating oil pressure alarm system for machine protection
High precision air and oil filters with 1-micron filtration accuracy
Magnets in hydraulic oil tank entrance to prevent rust and debris from entering
Cooling System
Built-in sealed exhaust fan to prevent overheating and extend service life
Stability & Safety
ISO TOPS/ROPS TEST analysis system for stability
Cast iron counterweight for balanced digging force
Waterproof key and safety seat with seatbelt for added protection
Shock Mitigation System
Enhanced shock absorption with rubber cushions and flexible coupling
If you require any further information on this listing please contact info@reflowx.com
Technical Details
| Model Number | HT-10C |
|---|---|
| Year of Manufacturing | 2026 |
