Hyundai Robex Mini Excavator 55-7 – 2013

The Hyundai Robex 55-7 Mini Excavator is a powerful and versatile 5.5-ton class excavator ideal for demanding applications in confined areas. Manufactured in 2013 by Beijing Hyundai Jingcheng Construction Machinery Co., Ltd., it features a turbocharged Yanmar 4TNV98 diesel engine delivering 39.3 kW (52.6 HP), optimized for performance and efficiency. The robust hydraulic system with a load sensing pump provides 182 L/min flow at 250 bar, enabling responsive and precise operations. The compact dimensions, strong undercarriage, and ergonomic cab design make this model a favorite for contractors requiring a dependable and mobile mini excavator.

Specifications:

– Brand: Hyundai
– Model: Robex 55-7
– Year of Manufacture: 2013
– Type: Mini Crawler Excavator
– Operating Weight: 5,500 kg (12,125 lbs)
– Engine Model: Yanmar 4TNV98
– Engine Type: 4-Cylinder, Turbocharged Diesel
– Power Output: 39.3 kW (52.6 HP) @ 2,300 rpm
– Displacement: 3.3 L
– Fuel Tank Capacity: 140 L
– Emission Standard: Stage IIIA
– Bucket Capacity: 0.2 m³ (0.26 yd³)
– Pump Type: Load Sensing Hydraulic System
– Hydraulic Flow: 182 L/min
– Operating Pressure: 250 bar
– Overall Length: 5,800 mm (19.0 ft)
– Overall Width: 2,200 mm (7.2 ft)
– Overall Height: 2,550 mm (8.4 ft)
– Undercarriage Length: 2,400 mm (7.9 ft)
– Track Width: 450 mm (1.5 ft)
– Track Length on Ground: 2,500 mm (8.2 ft)
– Ground Clearance: 350 mm (13.8 in)
– Serial Number: 905G72003
– Manufacture License: TS2510007-2013
– Manufacturer: Beijing Hyundai Jingcheng Construction Machinery Co., Ltd.
– Country of Origin: China (Beijing)

For further specifications or to inquire about this equipment and ReflowX's logistics services, Please contact ReflowX at info@reflowx.com
