JCB 4CX Backhoe Loader, 8.2 Ton, 109 HP – 2008

The 2008 JCB 4CX Backhoe Loader stands as one of the most capable and versatile machines in its class. Powered by the robust JCB DieselMax 4-cylinder turbocharged engine, it delivers 81.5 kW (109 hp) at 2,200 rpm, ensuring reliable performance in construction, utility, and infrastructure operations.

With an operating weight of approximately 8,200 kg (18,080 lbs), the 4CX is engineered to handle heavy-duty tasks with efficiency. Its loader bucket, ranging from 1.0 to 1.3 m³, is complemented by a backhoe bucket capacity of 0.2–0.3 m³, providing excellent versatility across various material handling jobs.

The machine offers a digging depth of 6,090 mm and a maximum reach of 6,360 mm from the swing post. With a lift capacity of up to 3,800 kg and a travel speed of 40 km/h, it ensures both power and mobility on the job site. The fuel tank capacity of 160 liters supports extended operation without frequent refueling.

Compact yet powerful, the JCB 4CX features dimensions that support operation in tight spaces—making it a preferred choice for contractors needing both strength and flexibility in a single machine.

Specifications:

– Product Type: Backhoe Loader
– Brand: JCB
– Model: 4CX
– Year: 2008
– Operating Weight: Approx. 8,200 kg (18,080 lbs)
– Engine Power: 81.5 kW (109 hp) @ 2,200 rpm
– Engine Type: JCB DieselMax 4-cylinder turbocharged
– Loader Bucket Capacity: 1.0 – 1.3 m³ (1.3 – 1.7 yd³)
– Backhoe Bucket Capacity: 0.2 – 0.3 m³ (0.26 – 0.39 yd³)
– Max Digging Depth (Backhoe): 6,090 mm
– Max Reach from Swing Post: 6,360 mm
– Max Lift Capacity (Loader): 3,800 kg
– Travel Speed: 40 km/h
– Fuel Tank Capacity: 160 liters
– Overall Length (with loader arm): 6,365 mm
– Overall Width: 2,510 mm
– Height to Top of Cab: 3,580 mm
– Wheelbase: 2,540 mm
– Ground Clearance: 380 mm
– Application Areas: Roadwork, material handling, trenching, site preparation, and utilities

For further specifications or to inquire about this equipment and ReflowX's logistics services, Please contact ReflowX at info@reflowx.com
