#2. JCB 535-140 Telehandler – 13.87m Boom Loader - 2012

The JCB 535-140 Telehandler, manufactured in 2012, is a versatile and powerful high-reach material handling machine designed for demanding tasks across construction, warehousing, and industrial operations. It offers a maximum lift height of 13.87 meters and a maximum forward reach of 9.75 meters, with a robust lifting capacity of 3,500 kg.

Powered by a JCB Diesel by Kohler 4-cylinder turbocharged diesel engine, this telehandler delivers 81 kW (109 HP) of power, ensuring efficient and reliable performance even under heavy loads. The hydraulic gear pump delivers a flow rate of 120 liters/min, enabling fast and smooth lifting with a full raise time of 11 seconds.

The machine is designed for optimal maneuverability with 3.85 meters turning radius, 0.40 meters ground clearance, and 12.5/80-18 tires, while the hydrostatic 4x4 transmission with 4 forward and 3 reverse gears ensures adaptable driving across varied terrain. Weighing 8,000 kg, the 535-140 offers a compact yet powerful solution for high-reach lifting tasks.

Specifications:

– Product Type: Telehandler / Boom Loader
– Brand: JCB
– Model: 535-140
– Year: 2012
– Max. Lift Capacity: 3,500 kg (3.5 tons)
– Max. Lift Height: 13.87 meters
– Max. Reach (Horizontal): 9.75 meters
– Engine Model: JCB Diesel by Kohler
– Engine Power: 81 kW (109 HP)
– Engine Type: 4-cylinder, Turbocharged Diesel
– Fuel Tank Capacity: 120 liters
– Hydraulic Pump Type: Gear Pump
– Hydraulic Flow Rate: 120 liters/min (High Flow)
– Max Lifting Speed: 11 seconds (fully raised)
– Max Travel Speed: 40 km/h
– Max Gradability: 45% (24°)
– Transmission Type: Hydrostatic 4x4
– Number of Gears: 4 Forward / 3 Reverse
– Tires: 12.5/80-18 (standard)
– Operating Weight: 8,000 kg
– Length (without attachments): 4.56 meters
– Width: 2.31 meters
– Height: 2.55 meters
– Wheelbase: 2.55 meters
– Ground Clearance: 0.40 meters
– Turning Radius: 3.85 meters (to the outside of the tire)
– Application Areas: Construction, infrastructure, warehousing, prefabricated structures, logistics

For further specifications or to inquire about this equipment and ReflowX's logistics services, Please contact ReflowX at info@reflowx.com
