JLG 4394RT Scissor Lift – Rough Terrain Aerial Work Platform – 2014

The JLG 4394RT (2014) is a rugged, diesel-powered rough terrain scissor lift, designed to deliver elevated work performance on demanding outdoor sites. With a maximum working height of 14.5 meters (47.6 ft) and a platform capacity of 680 kg (1,500 lbs), it’s ideal for multi-worker access and tool handling at height.

The lift features a spacious 2.59 m × 1.83 m platform with an outreach extension of 0.91 meters (3 ft), allowing greater reach and productivity. The 4-wheel drive system and gradeability of 45% ensure powerful off-road mobility across uneven surfaces. The robust Kohler KDI 1903 TCR engine, producing 42.5 kW (57 hp), delivers the required power with high efficiency.

The unit’s hydraulic system operates at 225 bar pressure with 113 L/min pump flow, supporting steady lift operation with a lift speed of 70 seconds to full height. Safety and maneuverability are enhanced by tight turning radii—3.48 m inside and 5.13 m outside—as well as a 4.6 m horizontal reach, making it suitable for access around obstructions.

Specifications:

– Model: JLG 4394RT
– Year: 2014
– Type: Rough Terrain Scissor Lift
– Category: Aerial Work Platform / Scissor Lift

– Max Working Height: 14.5 m (47.6 ft)
– Max Platform Height: 12.5 m (41.0 ft)
– Platform Capacity: 680 kg (1,500 lbs)
– Platform Length: 2.59 m (8.5 ft)
– Platform Width: 1.83 m (6.0 ft)
– Outreach at Full Height: 0.91 m (3 ft)
– Horizontal Reach: 4.6 m (15.0 ft)

– Overall Length: 3.85 m (12.6 ft)
– Overall Width: 2.29 m (7.5 ft)
– Overall Height: 2.56 m (8.4 ft)
– Ground Clearance: 0.23 m (9.0 in)

– Lift Speed: 70 seconds (to full height)
– Drive Speed (Max): 5.8 km/h (3.6 mph)
– Gradeability: 45%
– Turning Radius (Inside): 3.48 m (11.4 ft)
– Turning Radius (Outside): 5.13 m (16.8 ft)

– Engine Model: Kohler KDI 1903 TCR
– Engine Power: 42.5 kW (57 hp)
– Engine Type: Diesel, 4-cylinder, Turbocharged
– Fuel Type: Diesel
– Drive Type: 4WD (4-Wheel Drive)

– Hydraulic System Pressure: 225 bar (3,250 psi)
– Pump Flow: 113 L/min (30 GPM)
For further specifications or to inquire about this equipment and ReflowX's logistics services, Please contact ReflowX at info@reflowx.com
