KOMATSU FD30HT-17 Forklift Truck – 3 Ton – 2012

The KOMATSU FD30HT-17 is a rugged and efficient 3-ton diesel forklift, built for heavy-duty material handling applications. Manufactured in 2012, it features a powerful Komatsu S4D95 4-cylinder diesel engine producing up to 55 kW (74 HP) and delivering 240 Nm of torque. Its hydrostatic or torque converter transmission offers smooth, responsive control in various terrain and industrial environments.

Designed for high lifting demands, this model supports a maximum fork height of 4,500 mm, with standard 1,200 mm forks and a 500 mm load center. The forklift is available with either duplex or triplex masts, allowing configuration flexibility based on free lift and overhead clearance requirements. It provides a free lift height of 150–200 mm, ideal for containerized operations and low-ceiling environments.

The forklift achieves a maximum travel speed of 20 km/h (unladen) and a gradeability of up to 25%, supported by robust chassis and solid ground clearance of 160 mm. Lift and lowering speeds of 480 mm/s and 450 mm/s (respectively) under full load ensure optimal productivity on-site.

With a turning radius of approximately 2,400 mm, and overall compact dimensions (3,270 mm L × 1,850 mm W × 4,500 mm H with mast raised), the FD30HT-17 provides maneuverability without compromising load handling capacity. Its 70–80 liter diesel tank ensures extended operation with fewer refueling stops.

Specifications:

– Model: Komatsu FD30HT-17
– Year: 2012
– Type: Diesel-Powered Forklift Truck
– Load Capacity: 3,000 kg (3 tons)
– Load Center: 500 mm

– Mast Type: Duplex or Triplex (based on configuration)
– Max. Fork Height: 4,500 mm
– Free Lift Height: 150–200 mm
– Lift Speed (Loaded): 480 mm/s
– Lowering Speed (Loaded): 450 mm/s
– Fork Length: 1,200 mm (standard)

– Engine Model: Komatsu S4D95
– Engine Type: 4-cylinder, Water-cooled Diesel
– Engine Power: 55 kW (74 HP approx.)
– Max. Torque: 240 Nm
– Fuel Type: Diesel
– Fuel Tank Capacity: 70–80 liters
– Transmission: Hydrostatic or Torque Converter, 3-speed Automatic
– Max. Travel Speed (Unladen): 20 km/h
– Gradeability: 20–25%

– Overall Length: 3,270 mm
– Overall Width: 1,850 mm
– Overall Height (Mast Raised): 4,500 mm
– Turning Radius: 2,400 mm (approx.)
– Ground Clearance: 160 mm

For further specifications or to inquire about this equipment and ReflowX's logistics services, Please contact ReflowX at info@reflowx.com
