Toyota Diesel Forklift Truck : 62-8FD30

ReflowX SKU: REF-1966

Product Details

Quantity

5
Availability (Lead Time)

0-2 Weeks
Product Location

United Arab Emirates
Condition

New
OEM

Toyota Industries Corporation, Japan
Equipment code

Get Quotation Whatsapp

Short Description

Brand: Toyota Model: 62-8FD30 Type: Diesel Forklift Truck Frame No.: 608FDJ35-91147 Attachment Code: FSVE6 Production Year: 2024

Description

Specifications

General Information

Brand: Toyota

Model: 62-8FD30

Type: Diesel Forklift Truck

Load Capacity: 3,000 kg (6,614 lbs)

Load Center: 500 mm (19.7 in)

Lift Height: 3,000 - 6,000 mm (118 - 236 in) (varies by mast option)

Mast Tilt (Forward/Backward): 6° / 11°

Fork Dimensions (Standard): 1,070 mm (42 in) Length × 125 mm (4.9 in) Width × 45 mm (1.8 in) Thickness

Wheelbase: 1,700 mm (66.9 in)

Engine Specifications

Engine Model: Toyota 1DZ-III

Engine Type: 4-Cylinder, Water-Cooled, Diesel

Displacement: 3.0 L (183 in³)

Power Output: 44 kW (59 HP) @ 2,500 rpm

Torque: 190 Nm (140 lb-ft) @ 1,600 rpm

Fuel Tank Capacity: 65 L (17.2 gal)

Emissions Compliance: Tier 4 Final / EU Stage V

Transmission & Drive System

Transmission Type: Automatic Powershift

Drive Axle: Heavy-duty industrial axle with wet disc brakes

Steering System: Hydrostatic Power Steering

Travel Speed (Loaded/Unloaded): 18 km/h (11.2 mph) / 19 km/h (11.8 mph)

Gradeability (Loaded): 33%

Hydraulic System

Hydraulic Flow Rate: 65 L/min (17.2 gal/min)

Hydraulic Pressure: 200 bar (2,900 psi)

Control System: Fingertip hydraulic control levers

Tires & Stability

Tire Type: Pneumatic or Solid (optional)

Front Tires: 28 × 9 - 15

Rear Tires: 6.50 - 10

Turning Radius: 2,400 mm (94.5 in)

Ground Clearance: 140 mm (5.5 in)

Operational & Safety Features

Toyota System of Active Stability (SAS) for Enhanced Safety

ROPS/FOPS Certified Overhead Guard

Hydraulic Power Steering for Smooth Maneuvering

Automatic Transmission for Seamless Operation

Multi-Function LCD Display for Operator Monitoring

Seatbelt and Adjustable Suspension Seat for Comfort

For further specifications or to inquire about this equipment and ReflowX's logistics services, Please contact ReflowX at info@reflowx.com

Technical Details

Model Number	62-8FD30
Height	2,130 mm
Width	1,235 mm
Length	2,705 mm
Weight	4,280 kg
ISO 15926 Pt 4	8373
PCA RDS Code	RDS11590075
CFIHOS ID	CFIHOS-30000567
Fuel type	Diesel

General Terms

ReflowX and the seller retain the right to evaluate and approve offers.
Buyers should verify quantities and conditions upon delivery.
After successful engagement, both buyer and seller manage communication for payment terms and delivery schedule.
All parties agree to adhere to ReflowX Terms and Conditions in transactions.
Buyers can request value-added services such as pre-purchase inspections, Expediting & Delivery Services through ReflowX. Contact us!
