XCMG XGT6015-8S Flat-Top Tower Crane – 8 Ton, 60m Jib - 2020

The XCMG XGT6015-8S is a modern flat-top tower crane built for demanding construction environments. Manufactured in 2020, it features a maximum lifting capacity of 8 metric tons and a 60-meter jib capable of supporting 1.5 tons at the tip. With a free-standing height of approximately 50 meters and extendable up to 200 meters via climbing, this crane is ideal for mid- to high-rise developments.

The mast dimensions of 1.6 m × 1.6 m and a mast section height of 2.5 or 3.0 meters offer structural stability. Hoisting is powered by a VFD-controlled multi-speed motor for smooth lifting. The 360° slewing mechanism is operated by a dual motor system, while the trolley uses frequency-controlled technology for precise movement.

Operators benefit from a fully enclosed ergonomic cabin with joystick controls, wide visibility panel, and a digital interface that includes load monitoring and wind speed indicators. The crane is equipped with comprehensive safety features such as a load moment limiter, overload protection, diagnostic systems, emergency stop function, and anti-collision interface compatibility. Operates on a 380V / 50Hz / 3-phase power supply.

Specifications:

– Model: XCMG XGT6015-8S
– Year of Manufacture: 2020
– Crane Type: Flat-top Tower Crane
– Max Lifting Capacity: 8 metric tons
– Jib Length: 60 meters
– Tip Load: 1.5 tons at 60 meters
– Free-Standing Height: ~50 meters
– Max Height with Climbing: Up to 200 meters
– Mast Dimensions: 1.6 m × 1.6 m
– Mast Section Height: 2.5 or 3.0 meters
– Hoisting System: VFD motor, multi-speed
– Slewing Mechanism: 360°, dual motor system
– Trolley Mechanism: Frequency-controlled
– Cabin: Enclosed, ergonomic design, joystick controls
– Display: Load monitoring, wind speed indicator
– Power Supply: 380V / 50Hz / 3-phase

For further specifications or to inquire about this equipment and ReflowX's logistics services, Please contact ReflowX at info@reflowx.com
