Globe Valve 1/2" Class 800 – LVF A105N FNPT Trim 8, Handwheel Operated
The LVF 1/2" #800 globe valve is engineered for precise throttling and flow regulation in high-pressure pipelines. Constructed with a forged A105N carbon steel body and featuring female NPT threaded ends, this valve provides robust durability and leak-tight performance. It includes Trim 8 internals, a bolted bonnet (BB), and an OS&Y stem design for long service life and easy maintenance. This model is fully compliant with NACE MR0103 and MR0175, making it suitable for demanding applications involving corrosive and sour media, such as oil & gas and chemical process systems.
Specifications:
– Valve Type: Globe Valve
– Size: 1/2 inch
– Pressure Rating: Class 800
– Body Material: A105N Forged Carbon Steel
– End Connections: FNPT (Female National Pipe Thread)
– Bore Type: Reduced Bore (RB)
– Trim: Trim 8
– Bonnet Type: Bolted Bonnet (BB)
– Stem Configuration: OS&Y (Outside Screw & Yoke)
– Operator: Manual Handwheel
– Compliance: NACE MR0103 / MR0175
– Applications: High-pressure flow regulation in chemical, oil & gas, petrochemical, and refinery industries
For further specifications or to inquire about this equipment and ReflowX's logistics services, Please contact ReflowX at info@reflowx.com
