Siemens SIPART PS2 – 6DR5010-0NG00-0AA0 Electro-Pneumatic Positioner

The Siemens SIPART PS2 (Model 6DR5010-0NG00-0AA0) is a highly reliable electro-pneumatic positioner designed to modulate the position of linear or rotary actuators based on a 4–20 mA input signal. Widely adopted in process automation, this positioner ensures precise valve control in applications across oil & gas, chemicals, water treatment, and power generation.

Operated via a loop-powered 4–20 mA signal, the SIPART PS2 uses a compressed air input (typically 1.4 to 6 bar) to drive pneumatic actuators. Its robust design supports continuous operation in both indoor and outdoor environments, thanks to its IP66 / NEMA 4X-rated housing that protects against dust, moisture, and direct water jets.

The unit is certified for use in hazardous areas, with ATEX approval for explosive atmospheres and CSA certification for North American markets. The housing is available in industrial-grade corrosion-resistant plastic or metal, offering versatility and durability in aggressive or corrosive process conditions.

It supports standard actuator mounting interfaces, including NAMUR and VDI/VDE patterns, and optional LCD display with pushbuttons enables local configuration and diagnostics.

Manufactured in France, the SIPART PS2 is a preferred choice for integrated valve control across a wide range of industrial environments.

Specifications:

– Brand: Siemens
– Model: SIPART PS2 – 6DR5010-0NG00-0AA0
– Device Type: Electro-pneumatic positioner
– Function: Controls valve position via 4–20 mA signal
– Application: Linear and rotary actuators in process automation
– Power Supply: 4–20 mA loop-powered
– Pneumatic Input: Compressed air for actuator control
– Air Supply Pressure: 1.4 to 6 bar (20 to 90 psi)
– Temperature Range: -40°C to +80°C
– Ingress Protection: IP66 / NEMA 4X
– Housing Material: Industrial-grade plastic or metal (corrosion-resistant)
– Certifications:
 – CE Certified
 – CSA Approved (Canada/US)
 – ATEX Certified (explosive atmospheres)
– Zone Classification: Suitable for hazardous areas (per ATEX directive)
– Display: Optional LCD with local buttons (configuration-dependent)
– Mounting: Compatible with NAMUR and VDI/VDE actuator interfaces
– Manufactured In: France
– Quantity Available: Specify upon request
– Delivery: On request / lead time applies

For further specifications or to inquire about this equipment and ReflowX's logistics services, Please contact ReflowX at info@reflowx.com
