JENBACHER J620 GS Natural Gas Engine – 3431 kW, 50 Hz, Inline 12-Cylinder - 2014

ReflowX SKU: REF-279

Product Details

Quantity

1
Availability (Lead Time)

0-2 Weeks
Product Location

Indonesia
Condition

Used
OEM

JENBACHER GAS ENGINES
Equipment code

CFIHOS-30000683
Total Price
Per Unit Price

$ 192,500.00

Short Description

High-efficiency JENBACHER J620 GS natural gas engine rated at 3431 kW, 50 Hz, with 71,000 operating hours. Partially dismantled unit with a brand-new alternator. Ideal for industrial and CHP power generation.

Description

JENBACHER J620 GS Natural Gas Engine – 3431 kW, 50 Hz, Inline 12-Cylinder - 2014

The JENBACHER J620 GS is a high-output, industrial-grade natural gas engine designed for continuous-duty power generation and combined heat and power (CHP) systems. Manufactured in 2014, this 12-cylinder inline engine delivers 3431 kW of electrical power at 50 Hz and 1500 RPM, making it suitable for use in industrial facilities, district heating plants, and utility-scale installations.

This unit has clocked approximately 71,000 operating hours and is currently in a partially dismantled state, likely for transport, maintenance, or upgrade purposes. Importantly, it comes equipped with a brand-new alternator, offering extended operational life and improved efficiency. The engine features a water-cooled, closed-loop cooling system, forced lubrication with oil cooler, and advanced combustion optimization to ensure high performance and durability.

Electrical efficiency ranges from 42% to 44%, with low NOx emissions (<250 mg/Nm³) and excellent fuel economy of 0.31–0.33 m³/kWh. The unit is CHP-compatible and offers exhaust heat recovery potential with an exhaust gas temperature of ~450–550°C and exhaust flow of 15,000–18,000 Nm³/h.

This engine is ideal for applications where electricity and thermal energy are both needed, as well as for utility grid support or backup generation in large-scale facilities. Currently located in Asia, this engine is available for immediate inspection and relocation.

Specifications:
– Model: Jenbacher J620 GS
– Manufacturer: Jenbacher
– Year of Manufacture: 2014
– Power Output (Electrical): 3431 kW
– Frequency: 50 Hz
– Engine Speed: 1500 RPM
– Engine Type: Four-stroke, inline 12-cylinder, spark-ignited gas engine
– Fuel Type: Natural Gas (adaptable to biogas/landfill gas)
– Cooling System: Water-cooled, closed-loop
– Lubrication System: Forced lubrication with oil cooler
– Compression Ratio: ~14.5:1
– Electrical Efficiency: ~42–44%
– Heat Rate: ~10,000–11,000 kJ/kWh
– Exhaust Gas Temperature: ~450–550°C
– Exhaust Flow: 15,000–18,000 Nm³/h
– Fuel Consumption: ~0.31–0.33 m³/kWh
– NOx Emissions: <250 mg/Nm³
– CO₂ Emissions: ~185–200 g/kWh
– Cylinder Bore: 160 mm
– Piston Stroke: 190 mm
– Lubricant Capacity: 600–900 litres
– Alternator: Brand-new (recently replaced)
– Starting System: Electric start
– Noise Level: ~85–90 dB(A)
– Container/Frame: Partially dismantled (check for completeness)
– Dimensions (L x W x H): ~6500 mm x 2300 mm x 3300 mm
– Weight: ~35–40 tons
– CHP Capability: Yes – suitable for cogeneration
– Application Suitability: Industrial, commercial, utility-grade power generation
– Engine Hours: ~71,000 hours
– Location: Asia
– Delivery: Immediate – shipping/logistics to be confirmed

For further specifications or to inquire about this equipment and ReflowX's logistics services, Please contact ReflowX at info@reflowx.com
