2-7/8" 4 ft Pup Joint – API 5CT, EUE Threaded & Coupled

The 2-7/8" 4 ft Pup Joint is a short tubing accessory designed for fine adjustments in tubing string length and component spacing in oil and gas wells. Manufactured from seamless tubing per API 5CT standards, it is built to the same strength, burst, and collapse specifications as standard tubing joints.

Equipped with External Upset Ends (EUE), this pup joint is compatible with standard tubing strings and ensures reliable makeup and pressure integrity. The 4-foot length provides increased flexibility during well completions, artificial lift installation, and surface tie-ins, especially when aligning packers, nipples, or other downhole equipment.

It is typically available in steel grades such as J55, N80, L80, and P110, and is used in both onshore and offshore production environments.

Specifications:

– Outside Diameter: 2-7/8" (73.0 mm)
– Length: 4 ft (1.22 m)
– Weight: Approx. 8.6 lb/ft (varies by grade and wall thickness)
– Total Joint Weight: ~34.4 lb (for standard 8.6# tubing)
– Grades Available: J55, N80, L80, P110
– Pipe Type: Seamless
– End Connection: EUE (External Upset End), threaded & coupled
– Thread Standard: API 5B / API 5CT
– Material Type: Carbon or Alloy Steel
– End Finish: Threaded, beveled ends with API EUE coupling
– Manufacturing Standard: API 5CT
– Traceability: Heat number and full mill test certification
– Applications: Tubing spacing adjustments, packer or nipple positioning, well completion tie-ins, artificial lift systems, testing assemblies
