20" 133# NT95-DE BIG OMEGA Seamless Conductor – R3 Range, Premium Gas-Tight Connection

The 20" 133# NT95-DE BIG OMEGA Seamless Conductor is a robust and corrosion-resistant conductor casing engineered for extreme well conditions, including HPHT and sour environments. Constructed from NT95-DE grade alloy steel, which provides enhanced strength, toughness, and sour service capability, this casing is ideal for structural and initial pressure control functions in oil and gas wells.

Equipped with the BIG OMEGA premium threaded connection, it features a metal-to-metal gas-tight seal, optimized thread geometry, and superior torque capacity, making it suitable for conductor casing operations where high axial and bending loads are expected. The connection's seal integrity and mechanical strength make it a preferred choice for offshore conductor strings or deep onshore wells with complex surface loads.

This casing is manufactured as seamless pipe, ensuring consistent mechanical properties throughout its length, and is supplied in R3 range (~40.0–42.0 ft), reducing the number of joints and improving rig-time efficiency.

Specifications:

– Outer Diameter: 20" (508.0 mm)
– Weight: 133 lb/ft (197.9 kg/m)
– Grade: NT95-DE (sour-service enhanced T95 equivalent)
– Connection Type: BIG OMEGA Premium Thread
– Pipe Type: Seamless
– Range: R3 (Length: ~40.0–42.0 ft / 12.19–12.80 m)
– Material Type: Quenched & Tempered Alloy Steel
– End Finish: Premium Threaded & Coupled
– Yield Strength: ≥95,000 psi (655 MPa)
– Tensile Strength: 105,000–125,000 psi (724–862 MPa)
– Collapse Pressure: As per grade NT95-DE performance
– Coupling OD: Matches or slightly exceeds casing OD
– Thread Sealability: Metal-to-metal, gas-tight seal
– Hardness: Typically < 23 HRC (NACE-compliant for sour service)
– Manufacturing Standard: API 5CT, ISO 13679 CAL IV compliant
– Applications: Offshore conductor casing, HPHT wells, sour service wells, heavy surface load environments

For further specifications or to inquire about this equipment and ReflowX's logistics services, Please contact ReflowX at info@reflowx.com
