3-1/2" 12.7# L80 TSH BLUE Tubing – R2 Range, API 5CT

The 3-1/2" 12.7# L80 TSH BLUE Tubing is a high-performance seamless tubing product used in oil and gas production operations where enhanced strength, gas-tight sealing, and sour service resistance are critical. Manufactured to API 5CT standards, this tubing is made from L80-grade quenched and tempered steel, providing excellent yield strength and moderate hardness for use in corrosive downhole environments.

Fitted with the TSH BLUE premium connection developed by Tenaris, the tubing features a metal-to-metal gas-tight seal, optimized thread profile, and superior structural integrity. TSH BLUE connections offer excellent compression, tension, and bending resistance, with minimal risk of galling or thread failure during makeup. It is widely used in HPHT, CO₂, and H₂S wells where gas seal reliability and tubing integrity are paramount.

Supplied in R2 range (approx. 28–32 ft), this tubing size is ideal for deviated wells, artificial lift completions, and critical production strings in both onshore and offshore applications.

Specifications:

– Outside Diameter: 3-1/2" (88.9 mm)
– Weight: 12.7 lb/ft (18.9 kg/m)
– Grade: API 5CT L80 Type 1
– Pipe Type: Seamless
– End Type: TSH BLUE Premium Thread
– Range: R2 (Length: ~28.0–32.0 ft / 8.53–9.75 m)
– Material Type: Quenched & Tempered Alloy Steel
– Yield Strength: 95,000–110,000 psi (655–758 MPa)
– Tensile Strength: ≥105,000 psi (724 MPa)
– Hardness: ≤23 HRC (NACE MR0175-compliant)
– Burst Pressure: As per API L80 rating
– Collapse Pressure: Based on wall thickness and grade
– Coupling OD: Matches or slightly exceeds tubing OD
– Thread Sealability: Metal-to-metal, gas-tight seal
– Manufacturing Standard: API 5CT, ISO 13679 CAL IV qualified
– Applications: Sour service wells, HPHT wells, artificial lift systems, deviated and horizontal completions

For further specifications or to inquire about this equipment and ReflowX's logistics services, Please contact ReflowX at info@reflowx.com
