7" 29# L80 TENARIS BLUE Casing – R3 Range, API 5CT Premium Connection

The 7" 29# L80 TENARIS BLUE Casing is a high-strength, corrosion-resistant tubular product designed for use in critical well environments, including sour gas, deep wells, and high-pressure/high-temperature (HPHT) completions. Manufactured from seamless steel and certified to API 5CT standards, this casing features the premium Tenaris Blue® connection for gas-tight, torque-resistant performance.

The L80 grade provides controlled yield strength and enhanced resistance to sulfide stress cracking, making it suitable for moderately corrosive environments. The Tenaris Blue connection offers superior sealability under tension, compression, and bending, making it a preferred choice for challenging downhole conditions.

Supplied in R3 range length (30–40 ft), the 7" 29# casing ensures reliable mechanical properties and operational safety in both onshore and offshore applications.

Specifications:

– Outside Diameter: 7" (177.8 mm)
– Weight: 29.00 lb/ft (43.15 kg/m)
– Grade: L80 Type 1
– Pipe Type: Seamless
– Connection Type: Tenaris Blue® (premium gas-tight connection)
– Thread Type: Metal-to-metal seal, no need for thread compound
– Length Range: R3 (30 ft – 40 ft / 9.14 m – 12.19 m)
– Body Yield Strength: ~95,000 psi (655 MPa)
– Collapse Pressure: As per API 5CT for L80 and wall thickness
– Burst Pressure: Per API 5CT (dependent on wall thickness)
– Tensile Strength: Minimum 95,000 psi (655 MPa)
– Coupling Type: Tenaris Blue integral or matching premium coupling
– Standard: API 5CT with PSL-1/PSL-2 options
– Material Properties: Quenched and tempered carbon steel
– End Finish: Premium threaded & coupled
– Applications: HPHT wells, sour gas environments, directional wells, liner tie-backs, gas injection wells

For further specifications or to inquire about this equipment and ReflowX's logistics services, Please contact ReflowX at info@reflowx.com
