Caterpillar G3516H Gas Generator Sets – 2000 kW, 50 Hz - 2023

ReflowX SKU: REF-9465

Product Details

Quantity

7
Availability (Lead Time)

0-2 Weeks
Product Location

Singapore
Condition

New
OEM

MAN
Equipment code

Power Generation
Total Price
Per Unit Price

$ 931,500.00

Short Description

Seven brand new CAT G3516H gas gensets, rated 2000 kW at 50 Hz, 400 V. Year of manufacture 2023. Zero operating hours, without radiator. Located EXW Singapore, ready for immediate delivery.

Description

7x Caterpillar G3516H Gas Generator Sets – 2000 kW, 50 Hz, 2023, Zero Hours

Offered for immediate sale are 7 units of brand new Caterpillar G3516H gas generator sets, each rated at 2000 kW, designed for high-efficiency continuous and prime power applications. These generators are manufactured in 2023, have zero running hours, and are in factory-new condition, currently stored EXW Singapore.
The sets are supplied without radiators, allowing for integration into customized cooling systems per site requirements. Detailed technical documentation is available upon request. These gensets are ideally suited for industrial, utility, and grid-support operations demanding reliable, high-output gas power generation.

Specifications:

Generator Set Details
– Manufacturer: Caterpillar
– Model: G3516H
– Type: Natural Gas Generator Set
– Output Rating: 2000 kW
– Voltage: 400 V
– Frequency: 50 Hz
– Phase: 3-phase
– Power Factor: 0.8 lagging
– Cooling System: Without radiator (remote or custom cooling required)
– Emissions Compliance: Typically capable of meeting NOx < 500 mg/Nm³ with appropriate configuration
– Control Panel: EMCP or site-configurable panel
– Operating Hours: Zero hours (brand new)
– Year of Manufacture: 2023
– Condition: Brand new
– Availability: Immediate
– Location: EXW Singapore
– Documentation: Complete set available
For further specifications or to inquire about this equipment and ReflowX's logistics services, Please contact ReflowX at info@reflowx.com

Technical Details

Model Number	G3516H
Year of Manufacturing	2023
Model Number	G3516H
Year of Manufacturing	2023
Manufacturer Name	Caterpillar
Height	2.4 meters
Width	2.3 meters
Length	5.2 meters
Weight	16,500 kg
Usage Hours	00
Color	Caterpillar Yellow
ISO 15926 Pt 4	7686
PCA RDS Code	RDS820799
CFIHOS ID	CFIHOS-30000534
Fuel type	Natural Gas
Output Power	2000 kW
Model Number	G3516H
Year of Manufacturing	2023
Manufacturer Name	Caterpillar
Height	2.4 meters
Width	2.3 meters
Weight	16,500 kg
Usage Hours	00
Temperature Range	-10°C to +50°C
Voltage	400 V
Color	Caterpillar Yellow
PCA RDS Code	RDS820799
CFIHOS ID	CFIHOS-30000534
Fuel type	Natural Gas
Output Power	2000 kW
Speed	1,500 rpm
Direction of Rotation	Counterclockwise
Design Specification	4-stroke, turbocharged, aftercooled, spark-ignited V16 natural gas engine
Normal Operating Temperature	80°C to 95°C
Explosion Protection Gas Group	IIA
Explosion Protection Temperature Class	Class T3
Lower Limit Operating Temperature	-10°C
Operation Continuous Intermittent	Designed for Continuous and Prime Operation
Upper Limit Operating Temperature	+50°C
Number Of Shafts	1 (main crankshaft)
Test Medium	Factory-tested with pipeline-grade natural gas
Test Pressure	34–207 kPa (5–30 psi)
Turbine Cycle	Otto Cycle
Insulation Class	Class H
