Caterpillar XGC1900 Gas Power Module (2022) – High-Performance Gas Generator Specs
product image
product image

CATERPILLAR XGC1900 Gas Power Module – 1900 kW Prime, EPA Tier 4 - 2022

ReflowX SKU: REF-4842

Product Details

  • Quantity
    1
  • Availability (Lead Time)
    N/A
  • Product Location
    India
  • Condition
  • OEM
    Caterpillar Inc.
  • Equipment code
    Power Generation
  • Total Price
  • Per Unit Price
    $ 1,617,000.00
Whatsapp

Short Description

High-efficiency CATERPILLAR XGC1900 natural gas power module with 1900 kW prime and 2100 kW standby output. Powered by G3520C engine, the 2022 module meets Tier 4/EU Stage V standards and features advanced emissions control and water-cooled design.

Description

CATERPILLAR XGC1900 Gas Power Module – 1900 kW Prime, EPA Tier 4 - 2022

The CATERPILLAR XGC1900 Gas Power Module, introduced in 2022, is a robust and high-output natural gas generator designed for industrial, utility, and distributed generation applications. At its core is the Caterpillar G3520C V12 engine, a 4-stroke, turbocharged, and intercooled powerhouse displacing 58.9 liters, engineered for durability and high performance.

This unit delivers 1,900 kW (2,550 HP) of prime power and up to 2,100 kW (2,820 HP) on standby, operating at 1800 RPM and 60 Hz. The engine utilizes an advanced electronic governor and a closed-loop water cooling system, ensuring operational reliability even under demanding conditions.

Fuelled by natural gas, the module is highly fuel-efficient with a thermal efficiency of 41–42%. Daily fuel consumption is approximately 1,860–1,900 m³/day at full load. The emissions profile is optimized via a factory-integrated three-way catalyst (TWC) and after-treatment system, fully compliant with EPA Tier 4 and EU Stage V standards.

The module includes a Caterpillar MARINE or Open Drip-Proof (ODP) alternator, depending on setup, supporting voltages of 400V, 480V, 600V, and more. Safety features include overload, thermal, and short-circuit protection, along with a full-flow oil filtration system and 190-liter oil capacity, with change intervals every 500 hours.

Ideal for grid support, oil & gas fields, remote installations, or continuous industrial use, the CATERPILLAR XGC1900 is built for maximum uptime, performance, and compliance in today's energy landscape.

Specifications:
Model: CATERPILLAR XGC1900 Gas Power Module
Year of Manufacture: 2022
Engine Model: Caterpillar G3520C
Engine Type: 4-stroke, turbocharged, intercooled
Engine Configuration: V12
Displacement: 58.9 L (3595 cu in)
Bore × Stroke: 159 mm × 159 mm (6.26 in × 6.26 in)
Compression Ratio: 12.5:1
Governor Type: Electronic
Fuel Type: Natural Gas
Prime Power Output: 1900 kW (2550 HP) @ 1800 RPM
Standby Power Output: 2100 kW (2820 HP) @ 1800 RPM
Frequency: 60 Hz (50 Hz available on request)
Speed: 1800 RPM
Thermal Efficiency: 41–42%
Cooling System: Closed-loop, water-cooled
Exhaust System: Integrated with three-way catalyst (TWC) and after-treatment
Emissions Compliance: EPA Tier 4, EU Stage V
Alternator Type: Caterpillar MARINE or ODP (Open Drip-Proof)
Voltage Output Options: 400V / 480V / 600V (customizable)
Power Factor: 0.8 lagging
Protection Features: Overload, thermal, short-circuit
Dimensions (L × W × H):
 • 5850 mm × 2135 mm × 2840 mm (230 in × 84 in × 112 in)
Weight: Approx. 19,800 kg (43,600 lbs), depending on configuration
Applications: Distributed generation, industrial facilities, oil & gas fields, continuous duty

For further specifications or to inquire about this equipment and ReflowX's logistics services, Please contact ReflowX at info@reflowx.com
