Caterpillar 3508B Generator Set – 910 kW / 1137 kVA – 400V, 60 Hz – 3 Phase

ReflowX SKU: REF-4007

Product Details

Quantity

1
Availability (Lead Time)

0-2 Weeks
Product Location

United Arab Emirates
Condition

Surplus
OEM

Caterpillar Inc.
Equipment code

gen-d

Get Quotation Whatsapp

Short Description

Used CAT 3508B diesel generator set rated at 910 kW prime power (1137 kVA), 400V, 60 Hz, 3-phase configuration. Reliable standby or continuous power unit.

Description

Caterpillar 3508B Generator Set – 910 kW / 1137 kVA – 400V, 60 Hz – 3 Phase

Offered for sale is a Caterpillar 3508B diesel generator set, delivering 910 kW (1137 kVA) of prime power at 60 Hz in a 3-phase, 400V configuration. Built for performance and durability, this unit features CAT’s robust 3500-series engine platform, ideal for industrial, commercial, or backup power needs. The generator includes an integrated control panel, excitation system, and high-reliability cooling. Suitable for demanding environments requiring consistent power output.

The generator appears well-maintained and ready for deployment. Ideal for buyers seeking dependable power in mining, oilfield, utility, or remote site applications.

Specifications:

– Manufacturer: Caterpillar
– Model: 3508B
– Fuel Type: Diesel
– Rated Power: 910 kW (Prime)
– Apparent Power: 1137 kVA
– Voltage: 400V
– Frequency: 60 Hz
– Phases: 3 Phase
– Power Factor: 0.8
– Excitation Voltage: 32V
– Excitation Amperage: 7.01 Amps
– Frame: 695
– Speed: 1500 RPM
– Insulation Class: H
– Max Temperature Rise: 105°C by resistance
– Ambient Temp Rating: 40°C
– Enclosure Type: Open skid-mounted
– Condition: Used
– Location: UAE
For further specifications or to inquire about this equipment and ReflowX's logistics services, Please contact ReflowX at info@reflowx.com

Technical Details

Model Number	3508B
Model Number	3508B
Manufacturer Name	Caterpillar
Height	2,048 mm
Width	1,784 mm
Length	4,031 mm
Weight	12,475 kg
Temperature Range	-10°C to +40°C
Voltage	400V
ISO 15926 Pt 4	2353
PCA RDS Code	RDS873359
CFIHOS ID	CFIHOS-30000804
Output Power	910 kW
Speed	1800 RPM
Direction of Rotation	Counterclockwise
IFC Class	IfcEngineGenerator
Operation Continuous Intermittent	Continuous and Standby rated
