Caterpillar C3.3 Diesel Generator – Enclosed Canopy Type

ReflowX SKU: REF-9851

Product Details

Quantity

4
Availability (Lead Time)

0-2 Weeks
Product Location

United Arab Emirates
Condition

New
OEM

Caterpillar-USA
Equipment code

gen-d

Get Quotation Whatsapp

Short Description

CAT C3.3 enclosed diesel generator delivering 30–50 kVA prime power, with robust 3.3L engine, brushless alternator, and weatherproof canopy. Ideal for commercial and industrial backup.

Description

Caterpillar C3.3 Diesel Generator – Enclosed Canopy Type

The Caterpillar (CAT) C3.3 Diesel Generator is a rugged and fuel-efficient power solution designed for reliable standby and prime power applications. Housed in a sound-attenuated enclosed canopy, this generator is built to perform in challenging outdoor and industrial environments. The C3.3 engine, a 4-cylinder water-cooled diesel unit, delivers up to 49.6 HP (37 kW) with fuel-efficient operation at approximately 8.5 liters per hour at 75% load. Available in 30–50 kVA prime output configurations (up to 55 kVA standby), this 3-phase generator includes brushless self-excited alternator technology with ±1.0% voltage regulation, insulation Class H, and IP23 protection. Ideal for utility, construction, and commercial sites requiring stable power and portability.

Specifications:

– Brand: Caterpillar (CAT)
– Model: C3.3
– Type: Diesel Generator (Enclosed Canopy Type)
– Prime Power Output: 30 – 50 kVA (varies by configuration)
– Standby Power Output: 33 – 55 kVA
– Phase: 3-Phase
– Frequency: 50Hz / 60Hz
– Voltage Options: 230V / 400V (adjustable)

– Engine Model: CAT C3.3
– Engine Type: 4-Cylinder, Water-Cooled Diesel
– Power Output: Up to 49.6 HP (37 kW)
– Displacement: 3.3 L
– Fuel Type: Diesel
– Fuel Tank Capacity: Approx. 120 L
– Fuel Consumption: ~8.5 L/h @ 75% Load
– Cooling System: Radiator Cooled
– Starting System: Electric Start

– Excitation System: Brushless, Self-Excited
– Voltage Regulation: ±1.0%
– Insulation Class: H
– Protection Class: IP23
– Power Factor: 0.8 (Lagging)

– Dimensions (L × W × H): Approx. 2,200 × 1,000 × 1,400 mm
– Dry Weight: Approx. 1,200 kg

For further specifications or to inquire about this equipment and ReflowX's logistics services, Please contact ReflowX at info@reflowx.com

Technical Details

Model Number	CAT C3.3
Model Number	CAT C3.3
Height	1,519 mm
Width	980 mm
Length	2,120 mm
Weight	1,002 kg
Temperature Range	-15°C to +50°C (standard operation)
Voltage	220–415 V (50 Hz)
Color	Yellow
ISO 15926 Pt 4	2353
PCA RDS Code	RDS873359
CFIHOS ID	CFIHOS-30000804
Output Power	33 kVA (Standby), 30 kVA (Prime)
Speed	1,500 rpm
IFC Class	IfcEngineGenerator
Explosion Protection Gas Group	Not applicable
Explosion Protection Temperature Class	Not applicable
Explosion Protection Zone	Not applicable
Lower Limit Operating Temperature	-15°C
Operation Continuous Intermittent	Continuous and Standby
Upper Limit Operating Temperature	+50°C
