Indoor Low Voltage Current Transformer – 0.72 kV

ReflowX SKU: REF-5055

Product Details

Quantity

4
Availability (Lead Time)

0-2 Weeks
Product Location

United Arab Emirates
Condition

New
OEM

Cruxtransformers
Equipment code

CFIHOS-30000362

Get Quotation Whatsapp

Short Description

Indoor low-voltage current transformer for measuring and protection applications, with rated primary current from 50A to 4000A, secondary current of 1A or 5A, accuracy classes from 0.2s to PS, and test voltages up to 8 kV.

Description

Indoor Low Voltage Current Transformer – 0.72 kV

This Indoor Current Transformer (CT) is designed for low-voltage measuring and protection applications up to 0.72 kV system voltage. Engineered for reliability and accuracy, it supports a rated primary current range of 50A to 4000A with a standard secondary output of 1A or 5A, making it suitable for a wide range of industrial, utility, and commercial metering systems.

With rated outputs (burdens) from 1.5 VA to 40 VA, this CT meets stringent accuracy requirements for both metering (accuracy classes: 0.2s, 0.2, 0.5, 0.5s, 1.0, 3.0) and protection (accuracy classes: 5P5 to 5P30, 10P5 to 10P30, and PS(X)). It is capable of withstanding test voltages of 3 kV and 8 kV, with short-time thermal current ratings up to 60 times In for 0.5 seconds, and dynamic current withstand up to 2.5 times Ith.

Designed for indoor installation, this CT ensures consistent performance in controlled environments and is ideal for use in switchboards, control panels, motor control centers, and energy monitoring systems.

Specifications:

– Wide current range up to 4000 A for versatile system integration
– Dual-use accuracy classes for both protection and metering
– High dielectric strength with 3 kV / 8 kV test voltages
– Supports both 50 Hz and 60 Hz network frequencies
– High thermal and dynamic current withstand capability
– Compact indoor design for switchboards and control panels

– Application: Indoor Measuring / Protection
– Highest System Voltage: 0.72 kV
– Test Voltages: 3 kV (Power Frequency) / 8 kV (Impulse Withstand)
– Rated Primary Current (In): 50 A to 4000 A
– Rated Secondary Current: 1 A or 5 A
– Rated Output (Burden): 1.5 VA to 40 VA
– Rated Frequency: 50 / 60 Hz

Accuracy Classes:
– Metering CTs: 0.2s, 0.2, 0.5, 0.5s, 1.0, 3.0
– Protection CTs:
– 5P5, 5P10, 5P15, 5P20, 5P30
– 10P5, 10P10, 10P15, 10P20, 10P30
– PS (X) Class

Current Withstand Ratings:
– Rated Short-Time Thermal Current (Ith, 0.5s): 60 × In
– Rated Dynamic Current: 2.5 × Ith

For further specifications or to inquire about this equipment and ReflowX's logistics services, Please contact ReflowX at info@reflowx.com

Technical Details

Height	150 mm to 450 mm
Width	100 mm to 350 mm
Length	80 mm to 300 mm
Weight	3 kg to 20 kg
Usage Hours	00
Voltage	0.72 kV (720 V)
ISO 15926 Pt 4	3221
PCA RDS Code	RDS643994
CFIHOS ID	CFIHOS-30000362
IFC Class	IfcTransformer
Explosion Protection Gas Group	Not Applicable
Explosion Protection Temperature Class	Not Applicable
Explosion Protection Zone	Not Applicable
Insulation Class	Class E (120°C) or Class F (155°C) typically
Rated Primary Winding Voltage	0.72 kV
Rated Secondary Winding Voltage	5 A output or 1 A output
