Distribution Transformer – Oil-Immersed or Dry Type

ReflowX SKU: REF-5735

Product Details

Quantity

1
Availability (Lead Time)

0-2 Weeks
Product Location

United Arab Emirates
Condition

New
OEM

Al Budoor Transformers
Equipment code

CFIHOS-30000362

Get Quotation Whatsapp

Short Description

Medium-voltage distribution transformer up to 1000 kVA, available in oil-immersed or dry type designs, with primary voltage up to 33 kV and secondary options from 400V to 13.8kV.

Description

Distribution Transformer – Oil-Immersed or Dry Type

This medium-voltage distribution transformer is engineered for industrial, commercial, or utility-scale power networks, with a rating up to 1000 kVA. It supports primary voltages up to 33 kV and offers flexible secondary voltage options, including 400V, 415V, 11kV, and 13.8kV, with custom voltage configurations available on request. The unit is offered in both oil-immersed (ONAN) and dry-type cast resin (AN) versions, depending on installation environment and operational preferences.

The transformer supports both 50 Hz and 60 Hz frequencies, adaptable for global project requirements. It is built with Class A, F, or H insulation systems, depending on thermal performance needs. The robust design ensures reliability, energy efficiency, and long-term durability for various distribution network applications.

Specifications:

– Rated Power: Up to 1000 kVA
– Primary Voltage: Up to 33 kV
– Secondary Voltage Options:
– 400 V
– 415 V
– 11 kV
– 13.8 kV
– Custom voltages upon request
– Frequency: 50 Hz / 60 Hz (project-dependent)
– Transformer Type Options:
– Oil-Immersed Distribution Transformer
– Dry Type (Cast Resin) Distribution Transformer
– Cooling Method:
– ONAN (Oil Natural Air Natural) for oil-immersed type
– AN (Air Natural) for dry type
– Insulation Class: A / F / H
– Design Standard: Customizable as per IEC, ANSI, or project-specific standards
– Mounting: Floor-mounted or skid-type based on project layout

For further specifications or to inquire about this equipment and ReflowX's logistics services, Please contact ReflowX at info@reflowx.com

Technical Details

Height	1500 mm – 2200 mm
Width	1000 mm – 1800 mm
Length	1400 mm – 2500 mm
Weight	1500 kg – 3000 kg
Usage Hours	00
ISO 15926 Pt 4	3221
PCA RDS Code	RDS643994
CFIHOS ID	CFIHOS-30000362
IFC Class	IfcTransformer
Explosion Protection Gas Group	Not applicable
Explosion Protection Temperature Class	Optional T4 class
Explosion Protection Zone	Zone 2
Rated Primary Winding Voltage	Standard up to 33,000
Rated Secondary Winding Voltage	Common outputs: 11 kV, 6.6 kV, 3.3 kV, 400 V, or 230 V
