Compact Control Transformer – 10VA to 3000VA

ReflowX SKU: REF-285

Product Details

Quantity

4
Availability (Lead Time)

0-2 Weeks
Product Location

United Arab Emirates
Condition

New
OEM

Cruxtransformers
Equipment code

CFIHOS-30000362

Get Quotation Whatsapp

Short Description

Low-capacity control transformer rated 10VA to 3000VA with wide input/output voltage range, Class F/H insulation, IP00 protection, and panel or DIN rail mounting.

Description

Compact Control Transformer – 10VA to 3000VA

This Compact Control Transformer is designed for reliable performance in industrial control panels, offering input voltages from 100V to 600V and output voltages from 12V to 600V, with power capacity up to 3000VA. It supports global power system compatibility with dual-frequency operation (50/60 Hz).

The transformer uses Class F or H insulation, ensuring excellent thermal durability in high-load environments. Its IP00 enclosure rating is ideal for protected indoor installations inside electrical cabinets or enclosures. Panel mounting or DIN rail attachment options allow flexibility in system integration, even in compact spaces.

With clear terminal block connections, this transformer supports easy, organized wiring. It performs reliably in ambient temperatures up to 50°C and non-condensing humidity levels up to 85%. This makes it suitable for control circuits, isolation applications, instrumentation power, and auxiliary supply systems.

Specifications:

– Wide input/output voltage flexibility across control and automation systems
– Choice of panel or DIN rail mounting for modular installation
– High insulation class ensures thermal endurance and operational safety
– Compatible with both 50Hz and 60Hz power systems
– Reliable in high-humidity indoor environments
– IP00 protection rating for secure installation within electrical enclosures
– Clean, accessible terminal blocks for safe and organized wiring

– Input Voltage Range: 100V – 600V
– Output Voltage Range: 12V – 600V
– Power Capacity: 10VA to 3000VA
– Insulation Class: Class F / H
– Frequency: 50 Hz / 60 Hz
– Ambient Temperature: Up to 50°C
– Operating Humidity: 45% to 85%, non-condensing
– Protection Degree: IP00 (for cabinet installation)
– Mounting Type: Panel Mount / DIN Rail Mount
– Terminals: Terminal Blocks
For further specifications or to inquire about this equipment and ReflowX's logistics services, Please contact ReflowX at info@reflowx.com

Technical Details

Height	80 mm to 350 mm
Width	60 mm to 300 mm
Length	70 mm to 250 mm
Weight	Approx. 1 kg to 28 kg
Usage Hours	00
ISO 15926 Pt 4	3221
PCA RDS Code	RDS643994
CFIHOS ID	CFIHOS-30000362
IFC Class	IfcTransformer
Explosion Protection Gas Group	Not Applicable
Explosion Protection Temperature Class	Not Applicable
Explosion Protection Zone	Not Applicable
Insulation Class	Class B (130°C) standard
Rated Primary Winding Voltage	120 V, 208 V, 220 V, 230 V, 240 V, 277 V, 380 V, 400 V, 415 V, 480 V,600 V
Rated Secondary Winding Voltage	12 V, 24 V, 48 V, 120 V, 240 V
