Portable Safety Transformer – IP55 Rated

ReflowX SKU: REF-6575

Product Details

Quantity

1
Availability (Lead Time)

0-2 Weeks
Product Location

United Arab Emirates
Condition

New
OEM

Al Budoor Transformers
Equipment code

CFIHOS-30000362

Get Quotation Whatsapp

Short Description

Rugged and safe portable transformer for tools, lighting, and machinery on construction sites. Dry-type, IP55-rated, Class F insulated, and cast resin encapsulated for fire, water, and dust protection. Compliant with EN 60309-2 and DIN VDE 0623.

Description

Portable Safety Transformer – IP55 Rated

This portable safety transformer is engineered for demanding site applications including construction tools, lighting systems, and mobile machinery. Designed for full compliance with international electrical safety standards, it features a dry-type core using vacuum impregnation and cast resin encapsulation for maximum fire resistance, insulation, and environmental sealing.

With an insulation and temperature class of F, and a protection rating of IP55, the unit ensures reliable performance in rugged outdoor or industrial environments. Its enclosure—available in metal (RAL 7032) or reinforced fiberglass—offers fire retardance, dust and water resistance, and exceptional impact durability.

The transformer includes CEE panel-mounted receptacles (DIN VDE 0623 / EN 60309-2 compliant), MCB/ELCB protection, and cable glands for secure power input. Customization options such as socket count, current ratings, and enclosure material are available based on application-specific needs.

Specifications:

– Type: Portable Safety Transformer
– Power Application:
– Power Tools
– Temporary Lighting
– Machinery on Construction Sites
– Transformer Type: Dry Type
– Encapsulation: Cast Resin
– Insulation Class: F
– Temperature Class: F
– Protection Rating: IP55
– Enclosure Options:
– Metal Enclosure – Red & Yellow, RAL 7032
– Reinforced Fiberglass – Optional
– Enclosure Features:
– Fire Retardant
– Waterproof
– Dustproof
– High Impact Resistance
– Sealed Type with Cable Gland for Input Access
– Sockets: Number and rating as per application
– Socket Type: CEE Industrial Panel-Mounted Receptacles
– Protection Devices:
– ELCB / MCB based on load and safety requirement

For further specifications or to inquire about this equipment and ReflowX's logistics services, Please contact ReflowX at info@reflowx.com

Technical Details

Height	180 mm – 250 mm
Width	150 mm – 220 mm
Length	200 mm – 300 mm
Weight	10 kg – 30 kg
Usage Hours	00
ISO 15926 Pt 4	3221
PCA RDS Code	RDS643994
CFIHOS ID	CFIHOS-30000362
IFC Class	IfcTransformer
Explosion Protection Gas Group	Not applicable
Explosion Protection Temperature Class	T3 or T4 classes
Explosion Protection Zone	Optional Zone 2 or Zone 1 design
Rated Primary Winding Voltage	110 V, 220 V, 230 V, 400 V, 480 V AC
Rated Secondary Winding Voltage	12 V, 24 V, 48 V, 110 V, 230 V AC
