Low Power Control Transformer – 50VA to 1000VA

ReflowX SKU: REF-4384

Product Details

Quantity

2
Availability (Lead Time)

0-2 Weeks
Product Location

United Arab Emirates
Condition

New
OEM

Cruxtransformers
Equipment code

CFIHOS-30000362

Get Quotation Whatsapp

Short Description

Compact low power control transformer for voltage conversion and electrical isolation, rated from 50VA to 1000VA, with input/output voltages of 230V–600V. Ideal for industrial panels, instrumentation, and control systems.

Description

Low Power Control Transformer – 50VA to 1000VA

This Low Power Control Transformer is a compact, efficient, and robust solution for electrical isolation, voltage conversion, and instrumentation in control circuits. With a power rating range from 50VA to 1000VA, it supports input and output voltages from 230V to 600V, making it highly versatile for both step-up and step-down applications.

Designed for panel or optional DIN rail mounting, the transformer features terminal blocks for safe, secure, and vibration-resistant connections. Built with Class F or H insulation, it performs reliably in environments with ambient temperatures up to 50°C. The IP00 protection rating is suitable for enclosed control panels or equipment cabinets.

This transformer offers galvanic separation between input and output, ensuring safe electrical isolation and high measurement accuracy. It meets accuracy standards from Class 1 to Class 3, suitable for sensitive devices and voltage monitoring circuits.

Its modular and compact design makes it ideal for integration into industrial control panels, PLC systems, and measurement boards where stable voltage performance and electrical protection are critical.

Specifications:

– Electrical Isolation: Safe separation between input and output circuits
– Voltage Conversion: Step-up and step-down operation
– Protection Class: Enhanced electrical isolation and operator safety
– Accuracy Class: Class 1 / Class 2 / Class 3 (based on measurement precision)
– Design: Compact, modular for panel and instrumentation use
– Reliable Operation: Voltage stability and isolation under varying load conditions
– Safe Terminations: Rugged terminal blocks ensure secure connections
– Input Voltage: 230V – 600V
– Output Voltage: 230V – 600V
– Power Rating: 50VA to 1000VA
– Insulation Class: F / H
– Frequency: 50/60 Hz
– Ambient Temperature: Up to 50°C
– Protection Degree: IP00
– Terminals: Terminal Blocks
– Mounting Type: Panel / DIN Rail (optional)
For further specifications or to inquire about this equipment and ReflowX's logistics services, Please contact ReflowX at info@reflowx.com

Technical Details

Height	200 mm to 700 mm
Width	150 mm to 600 mm
Length	200 mm to 700 mm
Weight	10 kg to 80 kg
Voltage	120 V, 230 V, 400 V, 415 V, 690 V, 1000 V
ISO 15926 Pt 4	3221
PCA RDS Code	RDS643994
CFIHOS ID	CFIHOS-30000362
IFC Class	IfcTransformer
Explosion Protection Gas Group	Not Applicable
Explosion Protection Temperature Class	Not Applicable
Explosion Protection Zone	Not Applicable
Insulation Class	Class B (130°C) – standard
Rated Primary Winding Voltage	Typical: 230 V, 400 V, 415 V
Rated Secondary Winding Voltage	Typical: 24 V, 48 V, 110 V, 230 V
