SOLAR TAURUS 60 SoLoNOx Gas Turbine – 5.67 MW - 2023

ReflowX SKU: REF-7507

Product Details

Quantity

1
Availability (Lead Time)

2-4 Weeks
Product Location

India
Condition

New
OEM

Solar turbines incorporated
Equipment code

CFIHOS-30000685

Get Quotation Whatsapp

Short Description

Explore the Solar Taurus 60 SoLoNOx Gas Turbine (2023) with advanced combustion technology for low NOx emissions. Achieve high efficiency and reliability for power generation, cogeneration, and industrial applications. Discover full specs and performance features.

Description

SOLAR TAURUS 60 SoLoNOx Gas Turbine – 5.67 MW - 2023

High-efficiency SOLAR TAURUS 60 SoLoNOx industrial gas turbine rated at 5,670 kWe, with low-emission combustion, 12-stage compression, and 2023 manufacturing date. Ideal for power generation, CHP, and gas compression applications.

Long Description:
The Solar Taurus 60 SoLoNOx is a modern, compact industrial gas turbine engineered for high-efficiency power generation, cogeneration (CHP), and gas compression applications. Built in 2023, this unit produces approximately 5,670 kWe in simple-cycle mode, delivering strong electrical performance along with ultra-low emissions via the SoLoNOx low-NOx combustion system.

The SoLoNOx system is designed to meet strict environmental standards, producing less than 25 ppm NOx and under 50 ppm CO at 15% O₂. This makes the Taurus 60 ideal for urban, industrial, or environmentally regulated environments. The turbine achieves a thermal efficiency of 34–38%, with potential for enhanced performance when integrated into CHP systems that recover steam—producing up to 58.9 tonnes/hour of steam based on setup.

With a 12-stage axial compressor and 2-stage turbine, this machine is engineered for operational stability, quick start-up (10–15 minutes), and long service life. Its full-pressure lubrication system, API/ISO-compliant vibration limits, and robust build make it a strong fit for critical infrastructure, utility-scale operations, and continuous-duty installations.

Available in a standard industrial footprint and weighing approximately 22,680 kg (50,000 lbs), the Solar Taurus 60 offers reliability, compact installation, and emissions compliance in a 2023-generation package.

Specifications:
– Model: Solar Taurus 60 SoLoNOx
– Manufacturer: Solar Turbines
– Year of Manufacture: 2023
– Application: Power Generation, Cogeneration (CHP), Gas Compression
– Power Output (Simple Cycle): ~5,670 kWe
– Thermal Efficiency (Simple Cycle): 34–38%
– Fuel Type: Natural Gas (primary); other gaseous fuels (secondary)
– Combustion System: SoLoNOx (Low-NOx combustion system)
– Steam Output (CHP Mode): 13.5 to 58.9 tonnes/hr
– Heat Rate: ~11,430 kJ/kWh (10,830 Btu/kWh)
– Exhaust Temperature: ~510°C (950°F)
– Exhaust Mass Flow: ~78,385 kg/hr (172,810 lb/hr)
– NOx Emissions: <25 ppm @ 15% O₂
– CO Emissions: <50 ppm @ 15% O₂
– Compressor Stages: 12
– Turbine Stages: 2
– Start-up Time: 10–15 minutes (cold start)
– Lubrication System: Full-pressure system
– Vibration: Meets API and ISO operational limits
– Operating Temperature Range: -10°C to +40°C (14°F to 104°F)
– Dimensions (L x W x H): 4.88 m x 2.44 m x 2.44 m (16 ft x 8 ft x 8 ft)
– Weight: ~22,680 kg (50,000 lbs)
– Condition: New/2023
– Installation Mode: Simple-cycle; CHP-capable
– Availability: Contact for delivery timelines
– Delivery Terms: Typically EXW or FOB upon agreement

For further specifications or to inquire about this equipment and ReflowX's logistics services, Please contact ReflowX at info@reflowx.com
