SEW-EURODRIVE Helical-Bevel Gearmotor - Explosion-Proof

The SEW-EURODRIVE KAF107/T12GD EDR132M4BE11 Helical-Bevel Gearmotor is a premium industrial drive solution designed for demanding environments requiring robust torque, safety, and efficiency. This gearmotor delivers 5.5 kW of power and is suitable for 400V 3-phase systems operating at 50 Hz. Its IP54-rated enclosure ensures protection against dust and water ingress, while the explosion-proof construction complies with ATEX requirements for hazardous zones 2 and 22. With high-quality construction, this gearmotor ensures long service life and reliable performance in sectors such as petrochemical, food processing, and heavy industry.

Specifications:

– Brand: SEW-EURODRIVE
– Model: KAF107/T12GD EDR132M4BE11/3/GKCC/TF/AST/W/AL
– Part Number: 01.1915642901.0001.13
– Type: Helical-Bevel Gearmotor
– Motor Power: 5.5 kW
– Voltage: 400V AC, 3-Phase
– Frequency: 50 Hz
– Speed Output: Variable (based on gear ratio)
– Protection Class: IP54
– Insulation Class: F (up to 155°C)
– Temperature Range: -20°C to +40°C
– Weight (gear unit): Approx. 341.056 kg
– Certifications: CE, Ex-proof (Zone 2 and Zone 22 compliant)
– Application Zones: Hazardous environments with explosive gas/dust
– Construction Features: Durable casing, reliable bearings, compact design
– Mounting: Foot or flange-mounted depending on configuration

For further specifications or to inquire about this equipment and ReflowX's logistics services, Please contact ReflowX at info@reflowx.com
